LC-C4067U/N,LC-40E67UN,LC-40/46/52E77UN,LC-C46/5277UN,LC-46/52SB57UN
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[7] CABINET AND MECHANICAL PARTS (LC-52E77UN)(LC-C5277UN)
1 CCABAC225WJ01 BX N X Front Cabinet Ass'y (LC-52E77UN)
1 CCABAC225WJ03 BX N X Front Cabinet Ass'y (LC-C5277UN)
1-1 Not Available - - Front Cabinet
1-2 Not Available - N - Bottom Decoration A Ass'y
1-2-1 Not Available - N - Bottom Decoration A
1-2-2 Not Available - - SHARP Badge
1-3 Not Available - - Bottom Decoration B Ass'y
1-3-1 Not Available - N - Bottom Decoration B
1-3-2 HDECSA058WJ3A AM N X Shine Trim
1-4 Not Available - - LED Cover
1-6 XEBS740P10000 AB J Screw, x14
2 CCABBB432WJ01 BQ N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 HINDPD214WJSA AF N X Terminal label
3 CCOVAC951WJ02 AK N X Side AV Cover Ass'y
3-1 Not Available - N - Side AV Cover
3-2 Not Available - N - Side AV Label
4 CCOVAC952WJ01 AK X Key Button Cover Ass'y
4-1 Not Available - N - Key Button Cover
4-2 Not Available - N - Control Button Label
5 CSLDMB612WJ01 AV X Control Shield Ass'y
5-1 Not Available - N - Control Shield
5-2 PRDARA644WJFW AP X Control Radiator
5-3 XBPS730P06WS0 AA J Screw (for Radiator), x6
6 GCOVAC576WJKZ AC J VESA Hole Cover, x4
7 GCOVAD282WJ3A AN X Bottom Cover
8 HINDPD343WJSA AD N X Model Label (LC-52E77UN)
8 HINDPD346WJSA AD N X Model Label (LC-C5277UN)
9 LANGKB678WJN3 AV X Support Angle, x2
10 LANGKC082WJFW AC X MAIN PWB Angle
11 LHLDFA036WJKZ AB J Wire Holder (for Power PWB), x3
12 LHLDWA133WJKZ AC J Wire Holder
13 LHLDWA151WJKZ AB J Wire Holder, x3
14 LHLDWA172WJKZ AD J
Wire Holder
15 LHLDWA175WJUZ AC J Wire Holder, x3
16 LHLDWA176WJUZ AC J Wire Holder (for LW), x2
17 LHLDZB144WJKZ AH X Corner Lug, x2
18 LHLDZB145WJKZ AD X Center Lug, x2
19 LHLDZB388WJ3Z AG X Corner Lug (UP), x2
20 NSFTZA284WJFW AC J Hexagon Nut, x4
21 PMLT-A593WJZZ AC X Gasket:8X35X7T, x5
22 PMLT-A594WJZZ AD X Gasket:8X50X7T, x5
23 PMLT-A597WJQZ AF X Gasket (Tuner)
24 PSLDMB560WJFW AR X MAIN PWB Shield
25 PSPAZB963WJKZ AD J Conductor (Jack), x3
26 PSPAZC234WJKZ AG X Spacer D:23X23X3.5T
27 PSPAZC235WJKZ AL X Spacer A:35X15X4.5T
28 PSPAZC236WJKZ AL X Spacer B:35X23X3.5T
29 QCNCMA275WJQZ AC J Connecting Cord (MODEL SELECTOR), x2
30 QCNW-J147WJQZ AZ X Connecting Cord (LW:MAIN-LCD)
31 QCNW-G163WJQZ AF X Connecting Cord (LA:POW-INV)
32 QCNW-G170WJQZ AE X Connecting Cord (PL:POW-LCD)
33 QCNW-H495WJPZ AL X Connecting Cord (SP:MAIN-SP(L/R))
34 QCNW-J139WJQZ AM X Connecting Cord (PD:MAIN-POW)
35 QCNW-J140WJQZ AK X Connecting Cord (LP:MAIN-LCD)
36 QCNW-J141WJQZ AH X Connecting Cord (LB1:MAIN-POW)
37 QCNW-J142WJQZ AF X Connecting Cord (LB2:POW-INV)
38 QCNW-H493WJQZ AE X Connecting Cord (KM:MAIN-KEY)
39 QCNW-J144WJQZ AK X Connecting Cord (RA:MAIN-LED)
40 RSP-ZA413WJZZ AQ J Speaker (L)
41 RSP-ZA414WJZZ AQ J Speaker (R)
42 TLABK0023TAZZ AA J Bar Code Label
43 XBPS830P06000 AA J HDMI Screw, x4
44 XEBS930P10000 AA J Screw (for S-Video)
45 XEBS940P16000 AB J Screw (for CAB-A/B), x18
46 XHPS830P06WS0 AA J Screw, x39
47 XHPS840P08WS0 AB J Screw (for Lug), x10
48
XIPSN20P04000 AA J Screw (for Side HDMI), x2
