i
LCC4067U
Service Manual
OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE
This Service Manual covers the differences from LC-40E67U, LC-40E77U and LC-46E77U, LC-52E77U and LC-46SB57U, LC-52SB57U. For other
technical information, refer to the LC-40E67U, LC-40E77U (No. S39X4LC40E67U) / LC-46E77U, LC-52E77U (No. S37X3LC46E77U) / LC-
46SB57U, LC-52SB57U (No. S49Y6LC46SB57) Service Manual.
DIFFERENCES FROM BASE MODEL
LIST OF CHANGED PARTS (LC-C4067U)(LC-40E67UN)(LC-C4067UN)(LC-40E77UN)
Ref. No. Description
LC-40E67U
LC-40E77U
(No. S39X4LC40E67U)
LC-C4067U
LC-40E67UN
LC-C4067UN
LC-40E77UN
(No. S49Y7LC4067U/)
Note
PRINTED WIRING BOARD ASSEMBLIES
KEY Unit DUNTKE266FM02 ← —
MAIN Unit
DUNTKF030FM10
(LC-40E67U)
DUNTKF030FM16
(LC-C4067U)
No internal parts changed
DUNTKF030FM17
(LC-40E67UN)(LC-C4067UN)
DUNTKF030FM14
(LC-40E77U)
DUNTKF030FM17
(LC-40E77UN)
R/C, LED Unit DUNTKF096FM01 ← —
POWER Unit RDENCA354WJQZ ← —
LCD PANEL
40"LCD Panel Module
R1LK400D3LW10Z
(LC-40E67U)
←
(LC-C4067U)
—
R1LK400D3LW50Z
(LC-40E67UN)(LC-C4067UN)
Change
R1LK400D3LW20Z
(LC-40E77U)
R1LK400D3LW60Z
(LC-40E77UN)
Change
CABINET AND MECHANICAL PARTS
Please refer to a Parts list
PACKING PARTS, ACCESSORIES
Please refer to a Parts list
