Sharp LC-52E77UN User Manual

PARTS GUIDE
CONTENTS
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-C4067U/N,LC-40E67UN,LC-40/46/52E77UN,LC-C46/5277UN,LC-46/52SB57UN
LC-46SB57UN
LC-52SB57UN
LC-C4067U
LC-C4067UN
LC-40E67UN
LC-40E77UN
LC-46E77UN
LC-52E77UN
LC-C4677UN
LC-C5277UN
Note:
The reference numbers on the PWB are arranged
in alphabetical order.
No. S49Y7LC4067U/
MODELS
LCD COLOR TELEVISION
LC-C4067U
LC-C4067UN
LC-40E67UN
LC-40E77UN
LC-46E77UN
LC-52E77UN
LC-C4677UN
LC-C5277UN
LC-46SB57UN
LC-52SB57UN
PartsGuide
[1] PRINTED WIRING BOARD ASSEMBLIES
(LC-C4067U)(LC-40E67UN)(LC-C4067UN)(LC-40E77UN)
[2] PRINTED WIRING BOARD ASSEMBLIES
(LC-46E77UN)(LC-52E77UN)(LC-C4677UN)
(LC-C5277UN)(LC-46SB57UN)(LC-52SB57UN)
[3] LCD PANEL
(LC-C4067U)(LC-40E67UN)(LC-C4067UN)(LC-40E77UN)
[4] LCD PANEL
(LC-46E77UN)(LC-52E77UN)(LC-C4677UN)
(LC-C5277UN)(LC-46SB57UN)(LC-52SB57UN)
[5] CABINET AND MECHANICAL PARTS
(LC-C4067U)(LC-40E67UN)(LC-C4067UN)(LC-40E77UN)
[6] CABINET AND MECHANICAL PARTS
(LC-46E77UN)(LC-C4677UN)
[7] CABINET AND MECHANICAL PARTS
(LC-52E77UN)(LC-C5277UN)
[8] CABINET AND MECHANICAL PARTS
(LC-46SB57UN)
[9] CABINET AND MECHANICAL PARTS
(LC-52SB57UN)
[10] LCD MODULE Assembly
(LC-C4067U)(LC-40E67UN)(LC-C4067UN)(LC-40E77UN)
[11] LCD MODULE Assembly
(LC-46E77UN)(LC-C4677UN)(LC-46SB57UN)
[12] LCD MODULE Assembly
(LC-52E77UN)(LC-C5277UN)(LC-52SB57UN)
[13] SUPPLIED ACCESSORIES
(LC-C4067U)(LC-C4067UN)(LC-C4677UN)
(LC-C5277UN)(LC-40E67UN)(LC-40E77UN)
(LC-46E77UN)(LC-52E77UN)
[14] SUPPLIED ACCESSORIES
(LC-46SB57UN)(LC-52SB57UN)
[15] PACKING PARTS (NOT REPLACEMENT ITEM)
(LC-C4067U)(LC-40E67UN)(LC-C4067UN)(LC-40E77UN)
[16] PACKING PARTS (NOT REPLACEMENT ITEM)
(LC-46E77UN)(LC-52E77UN)(LC-C4677UN)
(LC-C5277UN)
[17] PACKING PARTS (NOT REPLACEMENT ITEM)
(LC-46SB57UN)
[18] PACKING PARTS (NOT REPLACEMENT ITEM)
(LC-52SB57UN)

Sharp LC-52E77UN Specifications

General

Brand	Sharp
Model	LC-52E77UN
Category	LCD TV
Language	English
