Page 6-2
File No. SG-0000242
JA1 CONNECTION [Main BD to SPEAKER ]
Pin Description
1 R+
2 R-
3 L+
4 L-
JL2 CONNECTION [Main BD to Panel Side]
Pin Description
1 LVDSVDD
2 LVDSVDD
3 LVDSVDD
4 LVDSVDD
5 LVDSVDD
6 NC
7 GND
8 GND
9 NC
10 NC
11 NC
12 NC
13 B2_RXE3+
14 B3_RXE3-
15 GND
16 B4_RXEC+
17 B5_RXEC-
18 GND
19 B6_RXE2+
20 B7_RXE2-
21 G0_RXE1+
22 G1_RXE1-
23 G2_RXE0+
24 G3_RXE0-
25 NC
