Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
6 1 9LE 011231061155 C/M Multi. 10uF 10V X5R 0805 L-F G Assembly Pull EA 19
C123,C128,C147,C165,C188,CA68,CP10,CP11,CP12,CP13,CP2,CP4,CP
42,CP5,CP64,CP65,CP7,CT32,CU22
6 *R* 9LE 011551061155 C/M Multi. 10uF 10V X5R 0805 G Assembly Pull EA 19
6 1 9LE 011231062554 C/M Multi. 10uF 25V X5R 1206 G Assembly Pull EA 3 CP57,CP68,CP75
6 *R* 9LE 011551062554 C/M Multi. 10uF 25V X5R 1206 G Assembly Pull EA 3
6 1 9LE 011232251615 C/M Multi. 2.2uF 16V X7R K 0805 G Assembly Pull EA 2 CV7,CV8
6 *R* 9LE 011132251615 C/M MULTI 2.2uF 16V X7R K 0805 L-F G Assembly Pull EA 2
6 *R* 9LE 011552251615 C/M MULTI 2.2uF 16V X7R K 0805 G Assembly Pull EA 2
6 1 9LE 011234751655 C/M Multi 4.7uF 16V X5R K 0805 L-F G Assembly Pull EA 1 CA51
6 *R* 9LE 011134751655 C/M Multi 4.7uF 16V X5R K 0805 L-F G Assembly Pull EA 1
6 *R* 9LE 011554751655 C/M Multi 4.7uF 16V X5R K 0805 G Assembly Pull EA 1
6 1 9LE 011234756056 C/M MULTI 4.7uF 6.3V X5R K 0603 G Assembly Pull EA 4 CA83,CA84,CW6,CW7
6 *R* 9LE 011554756056 C/M MULTI 4.7uF 6.3V X5R K 0603 G Assembly Pull EA 4
6 *R* 9LE 011134756056 C/M MULTI 4.7uF 6.3V X5R K 0603 L-F G Assembly Pull EA 4
6 1 9LE 013000001654 RES. CF 0ohm 1/16W J 0402 G Assembly Pull EA 30
R127,R133,R170,R171,R172,R173,R180,R182,R186,R189,R190,R191,RA
1,RA3,RA52,RH48,RL42,RL43,RL46,RL47,RS31,RU1,RU2,RV1,RV9,RW
16,RW17,RW18,RW7,RW8
6 1 9LE 013000001858 RES. CF 0.0ohm 1/8W J 0805 G Assembly Pull EA 7 FB3,FB9,RA43,RA48,RL59,RV12,RV18
6 1 9LE 013010000055 RES. CF 100ohm 1/10W J 0603 G Assembly Pull EA 1 RI11
6 1 9LE 013010001654 RES. CF 100ohm 1/16W J 0402 G Assembly Pull EA 20
R26,R28,RA53,RA54,RA65,RH25,RH26,RH27,RH28,RH29,RH33,RI15,RI
17,RI18,RI20,RP10,RP13,RT18,RT19,RT22
6 1 9LE 013010011459 RES. CF 1.0Kohm 1/4W J 1206 G Assembly Pull EA 1 RL2
6 1 9LE 013010011654 RES. CF 1Kohm 1/16W J 0402 G Assembly Pull EA 8 RH3,RH53,RH59,RI30,RP1,RP5,RP55,RW14
6 1 9LE 013010021654 RES. CF 10Kohm 1/16W J 0402 G Assembly Pull EA 29
R125,R30,RA23,RA26,RA42,RA56,RA69,RH55,RH60,RI28,RI32,RI33,RL3
,RL5,RL6,RP11,RP12,RP2,RP3,RP57,RP6,RP61,RP62,RP65,RP67,RP7,
RS24,RV13,RV15
6 1 9LE 013010031654 RES. CF 100Kohm 1/16W J 0402 G Assembly Pull EA 1 RA68
6 1 9LE 013010041654 RES. CF 1Mohm 1/16W J 0402 G Assembly Pull EA 2 R132,RI9
6 1 9LE 013010091859 RES. CF 10ohm 1/8W J 1206 G Assembly Pull EA 1 RI14
6 1 9LE 013012021654 RES. CF 12 Kohm 1/16W J 0402 G Assembly Pull EA 2 RV16,RV17
6 1 9LE 013012031654 RES. CF 120Kohm 1/16W J 0402 G Assembly Pull EA 1 RP74
6 1 9LE 013015001654 RES. CF 150ohm 1/16W J 0402 G Assembly Pull EA 1 RV19
6 1 9LE 013018001654 RES. CF 180ohm 1/16W J 0402 G Assembly Pull EA 1 RV10
6 1 9LE 013022001858 RES. CF 220ohm 1/8W J 0805 G Assembly Pull EA 1 RA91
6 1 9LE 013022031654 RES. CF 220Kohm 1/16W J 0402 G Assembly Pull EA 2 RI31,RI5
6 1 9LE 013022091654 RES. CF 22ohm 1/16W J 0402 G Assembly Pull EA 7 RA33,RA34,RA35,RA39,RA40,RA41,RL32
6 1 9LE 013024021654 RES. CF 24 Kohm 1/16W J 0402 G Assembly Pull EA 1 RP78
6 1 9LE 013030031654 RES. CF 300K ohm 1/16W J 0402 G Assembly Pull EA 2 RH66,RP83
6 61 9LE 013033001654 RES. CF 330ohm 1/16W J 0402 G Assembly Pull EA 1 RI13
6 1 9LE 013033081858 RES. CF 3.3ohm 1/8W J 0805 G Assembly Pull EA 4 RA10,RA7,RA8,RA9
6 1 9LE 013033090055 RES. CF 33ohm 1/10W J 0603 G Assembly Pull EA 5 RA47,RA51,RA80,RA81,RH24
6 1 9LE 013033091654 RES. CF 33ohm 1/16W J 0402 G Assembly Pull EA 8 RA31,RT23,RT26,RV2,RV5,RV8,RW10,RW2
6 1 9LE 013047000055 RES. CF 470ohm 1/10W J 0603 G Assembly Pull EA 4 RA37,RA38,RA72,RA73
6 1 9LE 013047011654 RES. CF 4.7Kohm 1/16W J 0402 G Assembly Pull EA 20
R144,R145,R146,R147,R165,R166,R42,R43,RA18,RA45,RA64,RH36,RH3
7,RI3,RI4,RS21,RT20,RT21,RV56,RV57
6 1 9LE 013047021654 RES. CF 47Kohm 1/16W J 0402 G Assembly Pull EA 9 RA49,RA66,RA78,RA79,RH20,RH21,RH22,RH23,RP59
6 1 9LE 013047031654 RES. CF 470Kohm 1/16W J 0402 G Assembly Pull EA 2 RA50,RL4
6 1 9LE 013047091654 RES. CF 47ohm 1/16W J 0402 G Assembly Pull EA 4 R115,R120,RH58,RS1
6 1 9LE 013051011654 RES. CF 5.1Kohm 1/16W J 0402 G Assembly Pull EA 1 RS25
Confidential-do not copy
Page 14-7
File No. SG-0000242
