LC-60C52U
4 – 5
22.Remove the 4 lock screws and detach the LCD Panel Module.
23.Remove the 8 lock screws and detach the Chassis Fix Angle T/B.
24
25
25
24
24
25
25
24
24
25
Chassis Fix
Angle T/B
LCD Panel Module
