LC-60G9T / LC-70G9T
5 – 17
11 ). KEY DATA INPUT
11.1) EDID DATA INPUT ( Main PWB : QPWBXG216WJ**)
ERUDECORPNOITIDNOCMETI
1 HDMI EDID
INPUT
ANALOG RGB
EDID INPUT
(Main PWB)
Inspection mode
Confirm the file
name/version.
1. Enter the Adjustment Mode.
2. Move cursor at [HDMI EDID WRITE] and press [ENT] key.
[OK] appear when finish.
(HDMI and Analogue RGB input data together)
[ Caution Item ]
Please execute data input after setting the model distinction.
The data based on model distinction information is recorded in
EEPROM.
11.2)MACADDRESS DATA INPUT (Main PWB : QPWBXG216WJ**)
Please refer to Document “Caution Item for Production “.
11.3)CIPLUS KEY DATA INPUT (Main PWB : QPWBXG216WJ**) [For X Model Only]
Please refer to Document “Caution Item for Production”.
11.4) WMDRM KEY DATA INPUT (Main PWB : QPWBXG216WJ**)
Please refer to Document “Caution Item for Production”.
12. CONFIRMATION ITEM
(1) HDMI-CEC Check
Confirm the operation of HDMI-CEC circuit.
(2) LAN Check
Confirm the connection and communication of PC and LAN terminal.
13. FACTORY SETTING
AC power is plug off after shipment setting is done.
Caution: Do not plug on again after shipment setting is done. If do, please re-do the shipment setting. Do not
off with remote control.
To Next Page
