50
LC-60LE635
LC-60LE638
Troubleshooting Table (continued)
[External input EXT3] No picture on the display (9)
Does not the picture of the COMPONENT signal input to EXT3 go out?
Do COMPONENT signals input to pins [13/COMP1_Y, 10/
COMP1_Pr, 11/COMP1_Pb] of EXT3 (J511)?
NO Check the setting of an external input device that connects with
EXT3.
YES
Do COMPONENT signals input to pins [AM16/COMP_Y1P),
(AJ18/COMP_PR1P) and (AK17/COMP_PB1P] of IC3303 (Digi-
tal AV decode & Main CPU)?
NO Check the line between J511 and IC3303.
YES
Refer to “No picture on the display (1)”
[External input PC] No picture on the display (10)
Does not the picture of the ANALOG-RGB signal input to PC_IN (15pin-D-SUB terminal) go out?
Do ANALOG-RGB and synchronized signal input to pin [(1, 2, 3)/
(PC_RED, GREEN, BLUE), (14 and 13)/(PC_VSYNC, H.Sync)]
of PC_IN (SC501)?
NO Check the connection and setup with the external PC_IN
devices.
YES
Do ANALOG-RGB and synchronized signal input to pins [AM15/
PC_RP, AK15/PC_GP, AK13/PC_BP, and AL13/PC_HSYNC,
AM13/PC_VSYNC] of IC3303 (Digital AV decode & Main CPU)?
NO Check the line between SC501 and IC3303.
YES
Refer to “No picture on the display (1)”
To Next Page
