Sharp LC-60LE638E - Page 86

86
LC-60LE635
LC-60LE638
1
2345678910
11 12
13
14
15 16
I
H
G
F
E
D
C
B
A
Power Unit Diagram RUNTKA847WJN1 (2 / 3)
R7321
C7910
1uF 25V K
C7911
10nF 50V K
R7324
5.11K 1/8W F
R7323
619 1/8W F
R7326
2K 1/8W F
D7307
BAS316
C7305
100nF 50V K
R7328
100 1/8W J
R7322
2K 1/8W F
TH7301
10K J
IC7301
TS321IDBVR
R7318
10 1/8W F
BU-OVP UR13V
UR13V''
D7901
NZX18C
1/2
C7916
470nF 50V K
R7932
34K 1/4W F
C7917
1nF 50V K
R7916
0 1/8W J
R7917
10K 1/8W F
PC7902
PS2561BL1-1-V-A(Q)
VCC_ON
AC
VCC
J7902
0 1/10W J
R7933
150K 1/4W F
IC7902
ST9S101-T6G
R7934
0 1/4W J
R7920
33K 1/8W F
J7901
1/2
EN
R7910
10K 1/8W F
R7931
10 1/8W F
PC7901
PS2561BL1-1-V-A(Q)
VCC_ON
D7905
NZX15B
D7902
BAS316
C7904
1nF 50V K
C7903
1nF 50V K
R7939
4.7K 1/8W J
Q7915
BT169B,126
C7912
1nF 50V J
Q7902
HIT667-TZ-EQ
C7914
2.2uF 16V K
VCC
1/2
R7918
2.2 1/2W J
C7915
47uF 63V M
D7904
EGP10DAMP
D7910
EGP10DAMP
C7918
1uF 100V M
R7919
200K 1/8W J
R7915
2K 1/8W J
R7912
2K 1/8W J
C7919
R7922
PC7903
PS2561BL1-1-V-A(Q)
D7906
UDZ15B-7
IC7905
TNY264PN
D7908
P6KE150AAMP
D7909
BYV26EAMP
R7921
360 1/4W J
R7911
14.7K 1/4W F
C7913
220nF 25V K
C7624
D7907
C7822
D7918
STPS5L60
C7928
470pF 200V J
C7926
470pF 200V J
D7911
1/2
C7929
1000uF 10V M
T7901
AV-DP10239
R7944
1K 1/8W F
R7946
0 1/8W J
R7943
100 1/8W F
C7920
C7935
PC7903
PS2561BL1-1-V-A(Q)
B+
R7914
2.2 1/2W J
FB7013
3.5 1
PC7902
PC7901
PS2561BL1-1-V-A(Q)
J7903
R7947
0 1/8W J
R7954
1K 1/8W F
R7950
10K 1/8W F
R7949
215 1/8W F
C7939
100nF 50V K
C7936
10nF 50V K
C7937
33nF 50V K
C7938
220uF 10V M
D7922
NZX5V6C
R7955
1K 1/10W F
C7941
220uF 10V M
1/2
DET
BU5V
R7957
301K 1/10W F
J7904
0 1/10W J
R7961
1K 1/10W F
R7956
1K 1/10W F
AC_DET
1/2
Q7901
PMBT4403
R7960
2K 1/4W F
R7958
1K 1/10W F
PC7904
PS2561BL1-1-V-A(Q)
C7302
470nF 16V K
C7300
100nF 25V K
R7303
1K 1/10W F
R7301
20K 1/10W F
R7300
10K 1/10W F
Q7300
PMBT4401,215
D7310
1N4148TA
Q7305
BT169B,126
PS_ON
1/2
PRO
DETBU5V
1/2
R7305
100 2W J
Q7301
PMBT4403
R7313
100 1/8W F
R7302
2K 1/10W F
C7301
100nF 16V K
R7304
100 1/8W F
D7903
NZX15B
C7933
IC7907
AS431ANTR-E1
PC7904
PS2561BL1-1-V-A(Q)
UR13V
VLED'
C7940
15nF 50V K
D7301
NZX16A
R7959
301K 1/10W F
R7307
1K 1/8W F
R7953
200 1/8W J
R7951
10K 1/8W F
R7308
D7302
IC7901
APL431LBAI-TRL
BU-OVP
D7311
BAS316
R7311
1K 1/10W F
D7317
