MD-MS200W/MD-MS200/MD-MS200H
– 14 –
7. NORMAL Mode
Step No.
Setting Method
Display
Step 1 Test mode STOP state [ T E S T ]
Step 2 BASS button
Step 3 AUTO menu [ A U T O ]
Step 4 SKIP UP button x 6times
(Or SKIP DOWN button x 4 times)
Step No.
Setting Method
Display
Step 5 NORMAL menu [ N O R M A L ]
Step 6 PLAY button
Step 7 TOC read [ Refer to the
following description.
]
Step 8 Hereafter operation in normal mode
• When the STOP button is pressed while the NORMAl menu appears, the mode changes to the TEST mode stop state.
• Indication during operation
Indication of memory capacity on main unit LCD [ ] + Level meter
: TNO
: Internal mode
: Servo state (#3: Slide, #2: Tracking, #1: Spin, #0: Focus)
: Address
LCD remote control [ ] + TNO indication
: Internal mode
: Servo state (#3: Slide, #2: Tracking, #1: Spin, #0: Focus)
: Address
: Memory capacity (graphic indication)
• Selection of sound volume, BASS, etc. is possible (without indication)
• Recording is also possible.
8. Digital input display mode
Step No.
Setting Method
Display
Step 1 Test mode STOP state [ T E S T ]
Step 2 BASS button
Step 3 AUTO menu [ A U T O ]
Step 4 SKIP UP button x 7times
(Or SKIP DOWN button x 3 times)
Step 5 Digital input indication menu [ D I N M O N ]
Step 6 PLAY button
Step No.
Setting Method
Display
Step 7 FS code, channel status indication [ C ƒ ƒ ƒƒ ƒƒ ]
Step 8 SKIP UP button
Step 9 U bit indication 1 [ U 1 ]
Step 10 SKIP UP button
Step 11 U bit indication 2 [ U 2 † † ‡ ‡ ]
Step 12 STOP button
Step 13 Test mode STOP state [ T E S T ]
• When the STOP button is pressed while the digital input indication menu appears or during digital input information indication, the mode
changes to the TEST mode stop state.
• In case of analog input or digital input unlocking the indication data is _.
• ƒ ƒ : Control Code
• ƒƒƒƒ : Category code
• : TNO
•
: INDEX
•
† † : TIME(min.)
•
‡ ‡ : TIME(Sec.)
