MD-MS200W/MD-MS200/MD-MS200H
– 44 –
58 P30 INPCNT Output Internal power control output
59 P31 EXPCNT Output External power control output
60 P32 DPCNT1 Output Mechanism driver power control output 1
61 P33 DPCNT2 Output Mechanism driver power control output 2
62 P34 LDPCNT Output Power control output for laser
63 P35 RFPCNT Output Power control output for RF circuit
64 BUZ BEEP Output Beep output
65 P37 SPCNT1 Output System power control output 1
66 P90 SPCNT2 Output System power control output 2
67 P91 CLKSTP Output 2 MHz clock control output
68 P92 MCPGIN Input Mic plug detection input
69 P93 INPGIN Input INPUT plug detection input
70 P94 INPGCK Input INPUT plug discrimination signal input
71 P95 OPTCNT Output Optical input circuit control output
72 P96 RCPCNT Output Record circuit power control output
73 P120 EMPHO Output Emphasis control output 0
74 P121 DAPON Ouput DA converter control output
75 P122 ADPON Output AD converter control output
76 P123 PBMUTE Output Playback audio IC control output
77 P124 PBAULT Ouput Data latch output for playback audio IC control
78 P125 RCAULT Output Data latch output for record audio IC control
79 P126 AUDATA Output Serial data output for audio IC control
80 P127 AUSCLK Output Serial clock output for audio IC control
81 IC IC Input Internal connection
82* X2 X2 Inout Not used
83 X1 X1 Input Main system clock input
84 VDD VDD Input Positive power supply
85* XT2 XT2 Input Not used
86 XT1 XT1 IInput Sub-system clock input
87 RESET RESET Input System reset input
88 T100 CIN Input Track cross signal input
89 T101 SPIN Input Spin motor rotational speed input
90 INTP2 DINT Input LSI interruption request signal
91 P03/INTP3 SENSE Input Servo status detection signal input
92 P04 FOK Input Focus OK signal input
93*,94* P05,06 P05,06 Output Not used
95 AVDD AVDD Input A/D converter analog power
96 AVREF0 AVREF0 Input A/D converter reference voltage input
97 ANI0 BATINN Input Built-in battery voltage detection input
98 ANI1 BATEXT Input External battery voltage detection input
99 ANI2 MODE0 Input Destination setting voltage detection input
100 ANI3 RKEY Input Remote control key input detection input
IC401 RH-iX2596AF02(IX2596AF):System Microcomputer (2/2)
Pin No.
FunctionPort Name Terminal Name
Input/Output
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
