Sharp MD-MS701H

PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MS701H/MS702H
– 1 –
L171 RCILC0333AFZZ J AC 10 µH,Choke
L201 VPBNNR47M0000 J AC 0.47 µH
L202 VPBNN100M0000 J AC 10 µH
L204 RCILC0353AFZZ J AB Tip Impeder
L452 RCILC0352AFZZ J AB Tip Impeder
L453,454 RCILC0290AFZZ J AC Tip Solid Induction,200mA
L456 RCILC0290AFZZ J AC Tip Solid Induction,200mA
L457,458 RCILC0290AFZZ J AC Tip Solid Induction,200mA
L491 VPBNN4R7M0000 J AC 4.7 µH
L500 VPANM4R7J0000 J AC 4.7 µH
L600 RCILC0331AFZZ J AC 2.2 µH,Choke
L601~604 RCILR0559AFZZ J AC 47 µH
L608 RCILC0246AFZZ J AC 100 µH,Choke
L609,610 RCILR0559AFZZ J AC 47 µH
L651 VPBNNR47M0000 J AC 0.47 µH
L702,703 RCILC0290AFZZ J AC Tip Solid Induction,200mA
L704 RCILC0352AFZZ J AB Tip Impeder
L710 VPBNNR47M0000 J AC 0.47 µH
L711 RCILC0352AFZZ J AB Tip Impeder
L712,713 RCILC0290AFZZ J AC Tip Solid Induction,200mA
L714 RCILC0290AFZZ J AC Tip Solid Induction,200mA
L751,752 RCILC0344AFZZ J AC 47 µH,Choke
L771 RCILR0559AFZZ J AC 47 µH
L772 VPANM4R7J0000 J AC 4.7 µH
L801 RCILC0330AFZZ J AC 1 µH,Choke
L821 RCILC0332AFZZ J AC 4.7 µH,Choke
L822 RCILC0333AFZZ J AC 10 µH,Choke
L841 RCILC0332AFZZ J AC 4.7 µH,Choke
L842 RCILC0333AFZZ J AC 10 µH,Choke
L862 RCILR0559AFZZ J AC 47 µH
L863 RCILC0332AFZZ J AC 4.7 µH,Choke
L871 RCILR0559AFZZ J AC 47 µH
L886 VPBNNR47M0000 J AC 0.47 µH
L887,888 RCORF0112AFZZ J AC Core
VIBRATOR
XL201 RCRSC0023AFZZ J AK Crystal,33.8688 MHz
CAPACITORS
C100 VCSAFA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C102,103 RC-KZ1193AFZZ J AC 1 µF,6.3V,Electrolytic
C104 VCKYTV1EB273K J AB 0.027 µF,25V
C106 RC-KZ1189AFZZ J AC 0.22 µF,16V,Electrolytic
C107 VCKYTV1EB123K J AB 0.012 µF,25V
C109 RC-KZ1193AFZZ J AC 1 µF,6.3V,Electrolytic
C110 RC-KZ1189AFZZ J AC 0.22 µF,16V,Electrolytic
C111 VCKYCY1HB332K J AA 0.0033 µF,50V
C112 VCKYCY1CB333K J AA 0.033 µF,16V
C121,122 VCCCCY1HH271J J AA 270 pF (CH),50V
C123,124 VCCSCY1HL391J J AA 390 pF,50V
C130 VCKYTV1CB104K J AA 0.1 µF,16V
C131 VCCCCY1HH331J J AA 330 pF (CH),50V
C161 RC-KZ1193AFZZ J AC 1 µF,6.3V,Electrolytic
C165 VCKYCY1CB333K J AA 0.033 µF,16V
C171,172 VCSAFB0JJ336M J AE 33 µF,6.3V,Electrolytic,Tantalum
C201 VCKYTV1CF105Z J AB 1 µF,16V
C202 VCSAFA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C203 VCKYCY1CB104K J AB 0.1 µF,16V
C205 VCKYCY1CB104K J AB 0.1 µF,16V
C207 VCKYCY1CB104K J AB 0.1 µF,16V
C211,212 VCCCCY1HH5R0C J AA 5 pF (CH),50V
C351 VCCCCY1HH101J J AA 100 pF (CH),50V
C353 VCSAFA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C354 VCKYCY1CB104K J AB 0.1 µF,16V
C357 VCKYCY1CB104K J AB 0.1 µF,16V
C361 VCKYTV1HB393K J AB 0.039 µF,50V
C401 VCKYCY1CB104K J AB 0.1 µF,16V
C431 VCKYCY1CB473K J AA 0.047 µF,16V
C441 VCCCCY1HH100D J AA 10 pF (CH),50V
C442 VCKYCY1HB681K J AA 680 pF,50V
C443 RC-KZ1191AFZZ J AC 0.47 µF,10V,Electrolytic
C451 VCKYCY1HB102K J AA 1000 pF,50V
C481 VCKYCY1CB104K J AB 0.1 µF,16V
C491 VCKYTV1CB104K J AA 0.1 µF,16V
C500 VCSAFA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C501,502 VCKYCY1HB222K J AA 0.0022 µF,50V
C503,504 VCSAFA1AJ335M J AD 3.3 µF,10V
C507 VCSAFA0JJ106M J AD 10 µF,6.3V,Electrolytic,Tantalum
C508 RC-KZ1193AFZZ J AC 1 µF,6.3V,Electrolytic
C509,510 VCKYTV1CF225Z J AC 2.2 µF,16V
INTEGRATED CIRCUITS
IC101 VHIIR3R55//-1 J AQ RF Signal,Processor,IR3R55
IC201 VHILR37648B-1 J BD ENDEC,LR37648B
IC202 RH-IX2567AFZZ J BA 4M D-RAM,IX2567AF
IC351 VHI74ACT02F-1 J AF Head Driver,74ACT02F
IC401 RH-IX2680AF03 J AX System Microcomputer,
IX2680AF
IC402 VHIS29L294A-1 J AH E
2
-PROM,S29L294A
IC404 VHI7SH00FU/-1 J AE NAND Gate,7SH00FU
IC431 VHIS80821LN-1 J AE 2.1V Reset,S80821LN
IC441 VHITC7W14FU-1 J AF Inverter,TC7W14FU
IC501 VHIAK4514VF-1 J AT AD/DA Converter,AK4514VF
IC601 VHIMPC17A39-1 J AQ Pickup Coil Driver,MPC17439
IC651 VHILB1638M/-1 J AH Motor Drive,LB1638M
IC701 VHIIR3R54N/-1 J AQ Audio Amp.,IR3R54N
IC702 VHITK71345M-1 J AE 4.5V Regulator (ON/OFF),
TK71354M
IC703 VHIIR3R54N/-1 J AQ Audio Amp.,IR3R54N
IC771 VHITK71225M-1 J AE 2.5V Regulator,TK71225M
IC800 VHIHN1C03FU-1 J AD Voltage Regulator,HN1C03FU
IC801 VHIHAT1025R-1 J AK Power Select,HAT1025R
IC803 VHINDH831N/-1 J AH N-ch MOS FET,NDH831N
IC804 VHIRN4904//-1 J AD Power Select Charge Drive,
RN4904
IC805 VHIUMD3N///-1 J AC Constant Current Drive,UMD3N
IC821 VHIIR3M09N/-1 J AL Power Drive,IR3M09N
IC841 VHIIR3M09N/-1 J AL Power Drive,IR3M09N
IC871 VHIS8327B30-1 J AG 3V DC/DC Converter,S8327B30
IC872 VHITC7W32FU-1 J AE C-MOS Logic,TC7W32FU
IC873 VHIS80827LN-1 J AE 2.7V Reset,S80827LN
IC874 VHITC7S00FU-1 J AD Charge Drive,TC7S00FU
IC875 VHITK71325M-1 J AE 2.5V Regulator (ON/OFF),
TK71325M
IC876 VHIRN4904//-1 J AD Power Select Charge Drive,
RN4904
IC901 VHIBA6965FV-1 J AN Spindle Motor Driver,BA6965FV
TRANSISTORS
Q101 VS2SA17457/-1 J AB Silicon,PNP,2SA17457
Q351 VS2SK2909//-1 J AE FET,2SK2909
Q352 VS2SK2911//-1 J AE FET,2SK2911
Q353 VS2SK2909//-1 J AE FET,2SK2909
Q354 VS2SK2911//-1 J AE FET,2SK2911
Q401 VS2SA17457/-1 J AB Silicon,PNP,2SA17457
Q711 VSRN1444A//-1 J AC Digital,NPN,RN1444 A
Q721 VS2SC4213B/-1 J AC Silicon,NPN,2SC4213 B
Q801 VS2SD1950//-1 J AD Silicon,NPN,2SD1950
Q802,803 VSDTC144EE/-1 J AB Digital,NPN,DTC144 EE
Q822 VHINDS335N/-1 J AF FET,NDS335N
Q842 VHINDS3335N/-1 J AF FET,NDS335N
Q871 VHINDS335N/-1 J AF FET,NDS335N
Q872 VSDTC144EE/-1 J AB Digital,NPN,DTC144 EE
Q873 VS2SJ305///-1 J AF FET,2SJ305
DIODES
D201 VHD1SS369//-1 J AD Silicon,1SS369
D351,352 VHDSB0209CP-1 J AC Silicon,SB0209CP
D431 VHD1SS361//-1 J AB Silicon,1SS361
D491~493 VHE015Z5R1Y-1 J AD Zener,5.1V,015Z5.1Y
D494 VHE15AZ7R5Y-1 J AC Zener,7.5V,15AZ7.5Y
D800 VHDRB491D//-1 J AD Silicon,RB491D
D801 VHE015Z5R1Y-1 J AD Zener,5.1V,015Z5.1Y
D802 VHDSB10015C-1 J AD Silicon,SB10015C
D821 VHDF1J2F///-1 J AE Silicon,F1J2F
D822 VHDRB521S30-1 J AC Silicon,RB521S30
D831 VHD1SS372//-1 J AD Silicon,1SS372
D841 VHDF1J2F///-1 J AE Silicon,F1J2F
D842 VHDRB521S30-1 J AC Silicon,RB521S30
D861 VHDRB491D//-1 J AD Silicon,RB491D
D862 VHDRB521S30-1 J AC Silicon,RB521S30
D871 VHDRB491D//-1 J AD Silicon,RB491D
D873 VHD1SS372//-1 J AD Silicon,1SS372
D875 VHD1SS378//-1 J AC Silicon,1SS378
D877 VHD1SS360//-1 J AB Silicon,1SS360
PH901 VHPGP1S93K/-1 J AF Photo Interrupter,GP1S93K
COILS
L100 VPBNN100M0000 J AC 10 µH
