PRICE
RANK
DESCRIPTIONNO.
PART CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MS701H/MS702H
R810,811 VRS-CY1JB184D J AA 180 kohms,1/16W
R814,815 VRS-CY1JB392D J AA 3.9 kohms,1/16W
R816 VRS-CY1JB122D J AA 1.2 kohms,1/16W
R817 VRS-TV2AB223J J AA 22 kohms,1/10W
R818 VRS-CY1JB103J J AA 10 kohm,1/16W
R819 VRS-CY1JB271J J AA 270 ohms,1/16W
R821 VRS-CY1JB104J J AA 100 kohm,1/16W
R823 VRS-CY1JB104J J AA 100 kohm,1/16W
R824 VRS-CY1JB153J J AA 15 kohms,1/16W
R826 VRS-CY1JB103J J AA 10 kohm,1/16W
R827 VRS-CY1JB304D J AA 300 kohms,1/16W
R828 VRS-CY1JB274D J AA 270 kohms,1/16W
R829 VRS-CY1JB333J J AA 33 kohms,1/16W
R831 VRS-CY1JB104J J AA 100 kohm,1/16W
R832 VRS-CY1JB335J J AA 3.3 Mohms,1/16W
R841 VRS-CY1JB104J J AA 100 kohm,1/16W
R843 VRS-CY1JB104J J AA 100 kohm,1/16W
R844 VRS-CY1JB153J J AA 15 kohms,1/16W
R846 VRS-CY1JB103J J AA 10 kohm,1/16W
R847 VRS-CY1JB334D J AA 330 kohms,1/16W
R848 VRS-CY1JB224D J AA 220 kohms,1/16W
R849 VRS-CY1JB333J J AA 33 kohms,1/16W
R851 VRS-CY1JB104J J AA 100 kohm,1/16W
R852 VRS-CY1JB155J J AA 1.5 Mohms,1/16W
R861 VRS-CY1JB104J J AA 100 kohm,1/16W
R872 VRS-CY1JB104J J AA 100 kohm,1/16W
R873 VRS-CY1JB102J J AA 1 kohm,1/16W
R874 VRS-CY1JB474J J AA 470 kohms,1/16W
R875~882 VRS-CY1JB104J J AA 100 kohm,1/16W
R901,902 VRS-CY1JB1R0J J AA 1 ohm,1/16W
R903 VRS-CY1JB151J J AA 150 ohms,1/16W
R904 VRS-CY1JB223J J AA 22 kohms,1/16W
R905 VRS-CY1JB104J J AA 100 kohm,1/16W
R906 VRS-CY1JB274J J AA 270 kohms,1/16W
R907 VRS-CY1JB184J J AA 180 kohms,1/16W
R908 VRS-CY1JB104J J AA 100 kohm,1/16W
R909 VRS-CY1JB103J J AA 10 kohm,1/16W
R921 VRS-CY1JB331J J AA 330 ohms,1/16W
R922 VRS-CY1JB104J J AA 100 kohm,1/16W
OTHER CIRCUITRY PARTS
CN101 QCNCW801XAFZZ J AH Socket,22Pin
CN451 QCNCW749PAFZZ J AE Socket,14Pin
CN482 QCNCW804GAFZZ J AD Socket,7Pin
CN601 QCNCW804RAFZZ J AE Socket,16Pin
CN701 QCNCWWQ33AFZZ J AE Socket,33Pin
J701 VHPGP1FB65R-1 J AP Jack,LINE
J702 QJAKM0189AFZZ J AE Jack,MIC IN
J703 QJAKM0201AFZZ J AH Jack,Headphones
J801 QJAKC0136AFZZ J AD Jack,DC IN
M901 RMOTV0500AFZZ J AT Motor Ass’y [Spindle]
M902 RMOTV0503AFZZ J AF Motor Ass’y [Sled]
M903 RMOTV0501AFM1 J AS Motor Ass’y [Lift]
SW401 QSW-M0171AFZZ J AC Switch,Push Type [EJECT]
SW402 QSW-S0948AFZZ J AC Switch,Slide Type [HOLD]
SW901 QSW-M0169AFZZ J AD Switch,Push Type [Disc In]
SW902 QSW-M0170AFZZ J AD Switch,Push Type [Disc Protect]
MECHANICAL PARTS
1 NGERH0597AFZZ J AC Wheel,Drive
2 NSFTD0328AFZZ J AE Screw,Drive
3 LHLDX3136AFM1 J AH Cartridge Holder Ass’y
4 MSPRT1607AFFJ J AB Spring,Cancel Lever
5 MLEVF2598AFFW J AD Lever,Eject
6 LCHSM0931AFM1 J AN Main Chassis Ass’y
7 PCUSG0599AFZZ J AB Cushion
8 QPWBH0306AFM1 J AQ Mechanism Flexible PWB Ass’y
8- 1 ———— J — Mechanism Flexible PWB
(Not Replacement Item)
8- 2(SW901) QSW-M0169AFZZ J AD Switch,Push Type [Disc In]
8- 3(SW902) QSW-M0170AFZZ J AD Switch,Push Type [Disc Protect]
8- 4(PH901) VHPGP1S93K/-1 J AF Photo Interrupter,GP1S93K
11 MSPRP0881AFFJ J AB Spring,
13 NGERH0596AFZZ J AD Gear,Drive
15 RCTRH8175AFZZ J BM Optical Pickup Unit
16 MSPRP0880AFFJ J AC Spring,Drive Grip
18 NSFTM0292AFFW J AC Shaft,Guide
20 MSPRT1604AFFJ J AB Spring,Eject Lever
23 QPWBH0307AFZZ J AF Magnetic Head Flexible PWB
25 MLEVF2599AFM1 J AE Lift Lever Ass’y
26 NGERH0595AFZZ J AC Gear,Lift Drive
28 MLEVF2600AFFW J AD Lever,Lift
29 MSPRD1353AFFJ J AB Spring,Lift Lever
30 LANGF1588AFFW J AD Bracket,Pickup
32 RCILH0109AFZZ J AN Magnetic Head
501 XSPSN14P01800 J AA Screw,ø1.4×1.8mm
502 LX-JZ0154AFZZ J AA Screw,ø1.4×2.8mm
503 LX-BZ0823AFZZ J AA Screw,ø1.4×1.2mm
504 LX-WZ9290AFZZ J AA Washer,ø0.8×ø2.4×0.25mm
505 LX-BZ0800AFZZ J AA Screw,ø1.4×2.5mm
506 LX-JZ0146AFZZ J AA Screw,ø1.7×2.5mm
507 LX-BZ0804AFFF J AA Screw,ø1.4×2.2mm
508 LX-BZ0960AFZZ J AB Screw,ø1.4×1.5mm
509 XSPSN14P01200 J AA Screw,ø1.4×1.2mm
510 LX-WZ9164AFZZ J AA Washer,ø1×ø2.4×0.25mm
511 LX-BZ0959AFZZ J AB Screw,ø1.4×1.8mm
512 LX-WZ9293AFZZ J AA Washer,ø2.7×ø5×0.25mm
513 LX-WZ9294AFZZ J AA Washer,ø1×ø2.4×0.15mm
M901 RMOTV0500AFZZ J AT Motor Ass’y [Spindle]
M902 RMOTV0503AFZZ J AF Motor Ass’y [Sled]
M903 RMOTV0501AFM1 J AS Motor Ass’y [Lift]
CABINET PARTS
201 GCABB2841AFSB J AG Front Cabinet [702H GY]
201 GCABB2841AFSC J AG Front Cabinet [701H]
201 GCABB2841AFSG J AG Front Cabinet [702H BL]
202 CCABD4342AF01 J AX Bottom Cabinet Ass’y [702H GY]
202 CCABD4342AF03 J AX Bottom Cabinet Ass’y [702H BL]
202 CCABD4352AF01 J AX Bottom Cabinet Ass’y [701H]
202- 1 ———— — Bottom Cabinet
(Not Replacement Item)
202- 2 GCOVA2218AFSA J AB Cover,DC Jack
202- 3 JKNBZ2040AFSA J AD Knob,HOLD
202- 4 PSHET0371AFZZ J AC Sheet,Bottom Cabinet
203 GFTAB1348AFSA J AC Lid,Battery [701H]
203 GFTAB1348AFSB J AC Lid,Battery [702H GY]
203 GFTAB1348AFSG J AF Lid,Battery [702H BL]
205 GCOVA2217AFSA J AD Cover,Eject [701H]
205 GCOVA2217AFSB J AD Cover,EJECT [702H GY]
205 GCOVA2217AFSF J AD Cover,EJECT [702H BL]
206 QTANZ9150AFFQ J AC Battery Terminal,-
207 QTANZ9149AFFQ J AC Battery Terminal,+
208 JKNBK0526AFSA J AE Knob,Eject
209 LANGK0934AFM1 J AN Main Frame Ass’y
210 PCUSG0649AFZZ J AB Cushion Machanism
211 PSHET0373AFZZ J AC Sheet
213 LANGZ0334AFM1 J AN Eject Bracket Ass’y
214 PCUSG0635AFZZ J AA Rubber,Preventive Vibration B
215 PCUSG0636AFZZ J AA Rubber,Preventive Vibration C
216 GCABA2839AFSA J AF Center Cabinet [701H]
216 GCABA2839AFSB J AF Center Cabinet [702H GY]
216 GCABA2839AFSF J AF Center Cabinet [702H BL]
217 PCUSG0534AFZZ J AC Rubber,Preventive Vibration
219 PSHET0378AFZZ J AB Sheet,Extention Battery Terminal
220 QTANZ9151AFFQ J AG Extention Battery Terminal
221 CCABC4329AF01 J AY Top Cabinet Ass’y [701H]
221 CCABC4330AF01 J AZ Top Cabinet Ass’y [702H GY]
221 CCABC4330AF05 J BA Top Cabinet Ass’y [702H BL]
221- 1 ———— — Top Cabinet
221- 2 HDECQ0528AFSA J AG Transparent Plate [701H]
221- 2 HDECQ0533AFSA J AG Transparent Plate [702H]
221- 3 HDECQ0529AFSA J AM Decoration Plate [701H]
221- 3 HDECQ0529AFSB J AM Decoration Plate [702H]
221- 4 PSHEZ0817AFZZ J AC Sheet,Transparent Plate
221- 5 PSHEZ0818AFZZ J AC Sheet,Decoration Plate
226 LANGK0935AFFW J AH Bracket,Knob
227 LHLDZ1706AFZZ J AD Holder,LCD
228 PCUSG0648AFZZ J AB Cushion,LCD
229 PCUSG0651AFZZ J AB Cushion,Bracket
231 RUNTK0442AFZZ J AP Key Flexible PWB Ass’y
232 RUNTZ0655AFZZ J AZ LCD
233 JKNBZ2042AFSA J AK Knob,Operation A [701H]
233 JKNBZ2042AFSB J AF Knob,Oparetion A [702H]
234 JKNBZ2043AFSA J AE Knob,Operation D [701H]
234 JKNBZ2047AFSA J AG Knob,Operation D [702H GY]
234 JKNBZ2047AFSB J AH Knob,Operation D [702H BL]
235 JKNBZ2044AFSA J AC Knob,Operation B
236 JKNBZ2045AFSA J AC Knob,REC [701H]
236 JKNBZ2048AFSA J AC Knob,REC [702H]
237 PCUSG0637AFZZ J AB Cushion A
238 PCUSG0652AFZZ J AB Cushion,Bracket
– 3 –
