● Volume level: “VOL 15”
● The above values are the standard values when the unit is charged and used at an
ambient temperature of 68˚F (20˚C).
● The playing time when using an alkaline battery may be different, depending on the
type and manufacturer of the battery and on the operating temperature.
Dimensions: Width: 3-7/16" (87 mm)
Height: 31/32" (24 mm)
Depth: 3-3/32" (78 mm)
Weight: 0.41 lbs. (184 g) with rechargeable battery
Output jack: Headphones (impedance: 19 ohms)/remote control unit
■ MiniDisc Player
Type: Portable MiniDisc player
Signal readout: Non-contact, 3-beam semi-conductor laser pick-up
Audio channels: 2
Frequency response: 20 – 20,000 Hz (± 3 dB)
Rotation speed: Approx. 400 – 900 rpm
Error correction: ACIRC (Advanced Cross Interleave Reed-Solomon Code)
Coding: ATRAC (Adaptive TRansform Acoustic Coding)
D/A converter: 1 bit
Sampling frequency: 44.1 kHz
Modulation system: EFM (Eight to Fourteen Modulation)
Wow and flutter: Unmeasurable (less than ±0.001% W. peak)
Output level:
Specified out-
put
Maximum
output level
Load
impedance
Headphones – 5 mW + 5 mW 32 ohms
LINE
250 mV
(–12 dB)
– 50 kohms
21
MD-S301
