9. Re-attach the upper cabinet front left to the main body and attach the IC card label (as shown):-
10. Turn ON the power of the main unit.
IC Card Reader Device Registration:
a. Enter the card reader setting menu as shown below.
System Settings - User Control - Administrator Login -Card Reader Device Registration
b. Press [Read] button.
c. Disconnect the connector which links the machine and the IC card reader, and then insert it back.
d. Press [OK] button.
e. Check to confirm that values are displayed on Product ID and Vender ID.
f. Press [SUBMIT] button, and check to confirm that the success dialog message is displayed.
IC Card Setting for Internal User Control:
a. Enter the card reader setting menu as shown below.
System Settings - User Control - Administrator Login - Card Type/Card Reader Settings.
b. Check Use IC Card for Authentication.
c. Press [Submit] button.
IC Card Recognition Check:
There are two check methods of IC card recognition - use either one to check that the IC card reader has
been recognized.
Check Method 1
Enter the card reader setting menu as shown below.
Home -Settings - System Settings - USB-Device Check
Check to confirm that Card Reader/Writer is displayed.
Check Method 2
Confirm that the card reader icon is displayed on the system area of the Home screen.
