20
SPECIFICATIONS
Punch module (for finisher)
Name
Punch module (MX-PN11B)
Paper size for punch module
11" × 17" (A3) to 7-1/4" × 10-1/2"R (A4)
Holes
3 holes
Required power supply
Supplied from finisher
Dimensions
3-55/64" (W) × 18-50/64" (D) × 5-26/64" (H)
(98 mm (W) × 477 mm (D) × 137 mm (H))
Weight
Approx. 7 lbs. (3 kg)
Saddle Finisher
Name
Finisher (MX-FN10)
Paper sizes
Depends on feeder specifications
Useable paper
Paper weight 15 lbs. bond (55 g/m
2
) to 110 lbs. cover (300 g/m
2
)
No. of trays
1
Tray capacity
(21 lbs. bond (80g/m
2
))
Non-stapled 12" × 18" (A3 wide) / 11" × 17" (A3) /
8-1/2" × 14" (B4) / 5-1/2" × 8-1/2"R (A5R): 500 sheets
8-1/2" × 11" (A4) / 8-1/2" × 11"R (A4R, B5) /
7-1/4" × 10-1/2"R (B5R): 1,000 sheets
Staple function 11" × 17" (A3) / 8-1/2" × 14" (B4): 30 sets or 500 sheets
8-1/2" × 11" (A4) / 8-1/2" × 11"R (A4R, B5, B5R):
30 sets or 1,000 sheets (For 8-1/2" × 11" (A4), 50 sets only
when stapled in a single location on the far side)
Offset output is not available for 12" × 18" (A3 wide) /
5-1/2" × 8-1/2"R (A5R).
Required power supply
Supplied from this machine
Weight
Approx. 88 lbs. (40 kg)
Dimensions
When output paper tray is stored
19-9/16" (W) × 24-27/32" (D) × 38-57/64" (H)
(497 mm (W) × 631 mm (D) × 988 mm (H))
When output paper tray is extended
25-53/64" (W) × 24-27/32" (D) × 38-57/64" (H)
(656 mm (W) × 631 mm (D) × 988 mm (H))
Max. no. of stapled sheets
Max. no. of 50 sheets (8-1/2" × 11" (A4), 8-1/2" × 11"R (A4R, B5, B5R))
Max. no. of 25 sheets (11" × 17" (A3), 8-1/2" × 14" (B4))
Staple position
1 bottom, 1 top, 2 middle
Staple method (for saddle stitch)
Centered fold with stapling in 2 center places
Saddle stitch fold position
Centered fold
Saddle usable sizes
11" × 17" (A3) / 8-1/2 × 14" (B4) / 8-1/2" × 11"R (A4R)
Saddle usable paper weight
16 lbs. bond (60 g/m
2
) to 110 lbs. index (220 g/m
2
)
Max. no. of saddle-stitched sheets
Max. no. of 15 sheets (21 lbs. bond (80 g/m
2
)):
14 sheets (21 lbs. bond (80 g/m
2
)) + 1 sheet (110 lbs. index (209 g/m
2
))
Finisher
Name
Finisher (MX-FN17)
Paper sizes
Depends on feeder specifications
Useable paper
Paper weight 15 lbs. bond (55 g/m
2
) to 110 lbs. cover (300 g/m
2
)
No. of trays
1
Tray capacity
(21 lbs. bond (80g/m
2
))
Non-stapled 12" × 18" (A3 wide) / 11" × 17" (A3) /
8-1/2" × 14" (B4): 250 sheets
8-1/2" × 11" (A4) / 8-1/2" × 11"R (A4R, B5) /
7-1/4" × 10-1/2"R (B5R) / 5-1/2" × 8-1/2"R (A5R):
500 sheets
Staple function 11" × 17" (A3) / 8-1/2" × 14" (B4): 30 sets or 250 sheets
8-1/2" × 11" (A4) / 8-1/2" × 11"R (A4R, B5) /
30 sets or 500 sheets
Offset output is not available for 12" × 18" (A3 wide) /
7-1/4" × 10-1/2"R (B5R) / 5-1/2" × 8-1/2"R (A5R).
Max. no. of stapled sheets
Max. no. of 50 sheets (8-1/2" × 11" (A4), 8-1/2" × 11"R (A4R, B5))
Max. no. of 30 sheets (11" × 17" (A3), 8-1/2" × 14" (B4))
Staple position
1 bottom, 1 top, 2 middle
Required power supply
Supplied from this machine
Weight
Approx. 26.4 lbs. (12 kg)
Dimensions
When output paper tray is stored
16-55/64" (W) × 23-22/64" (D) × 7-51/64" (H)
(428 mm (W) × 593 mm (D) × 198 mm (H))
When output paper tray is extended
24-6/64" (W) × 23-22/64" (D) × 7-51/64" (H)
(612 mm (W) × 593 mm (D) × 198 mm (H))
