Sharp MX-M264U Installation Manual

MX-M264U MX-M264U/M314U/M354U/M264N/M314N/M354N/M264NV/M314NV/M264NR/M314NR/M354NR (MAIN UNIT) 2 – 1
MX-M264U
6HUYLFH0DQXDO

[2] MX-M264U/M314U/M354U/M264N/M314N/M354N/M264NV/M314NV/
M264NR/M314NR/M354NR (MAIN UNIT)
1. Unpacking
A. Unpacking
B. Fixing tape and protection material removal
C. Packed items check
D. Lock release
(1) Tray rotation plate lock release
1) Pull out the tray. Turn the fixing material and remove it.
Remove the caution label.
Attach the removed fixing material to the position shown in the
figure for future use.
Close the tray which was pulled out.
(2) Scanner (2/3 mirror unit) lock release
1) Remove the optical unit fixing screw, and remove the note
label.
No. Name Quantity
1 Operation manual 1
1

Sharp MX-M264U Specifications

General

Brand	Sharp
Model	MX-M264U
Category	All in One Printer
Language	English
