Sharp MX-M316N - Fusing Section Maintenance Details

MAINTENANCE
SHARP
12
100K
150K
200K
300K
FUSING SECTION:
X
X
Replace: Upper Heat Roller Kit [MX-313UH]:-
 Upper heat roller.
 Fusing gear.
 Upper heat roller bearing x2.
 Upper cleaning pad.
 Upper separation pawl x4.
X
X
Check/Clean Thermistor.
X
X
Check/Clean Fuser Paper Guide.
X
X
Check/Clean Delivery Guide Collar Surface.
X
X
Sim 24-04 Clear FUSING ROLLER Counter.
X
X
Clear SEPARATE PAWL (U) Counter.
X
X
Clear CLEAN FELT Counter.
X
X
X
Replace: Lower Heat Roller Kit [MX-312LH]:-
 Lower heat roller.
 Lower heat roller bearing x2.
 Lower separation pawl.
X
X
X
Check/Clean Lower separation pawl.
X
X
X
Sim 24-04 Clear PRESS ROLLER Counter.
