TROUBLE CODES
SHARP
52
SHARP Document Solution Centre
F1
23
Finisher shutter trouble
30
Finisher-Saddle communication trouble
31
Saddle Finisher folding sensor trouble.
32
Finisher/Punch unit communication error.
33
Punch unit shift operation trouble.
34
Punch operation trouble.
36
Punch paper edge detection error
37
Finisher data backup RAM error.
38
Punch data backup RAM trouble.
39
Punch paper dust sensor trouble.
41
Saddle paper positioning trouble
42
Saddle guide motor trouble
43
Saddle alignment operation trouble.
44
Saddle staple motor R trouble
45
Saddle staple trouble.
46
Saddle pushing plate motor trouble
47
Saddle paper transport motor trouble.
50
Finisher incompatibility trouble.
51
Saddle sensor connection trouble
52
Finisher micro switch trouble
F2
22
Discharge lamp trouble (K)
39
Process temperature sensor trouble
40
Toner density sensor trouble (K)
45
Image density sensor trouble
50
K drum phase sensor trouble
58
Temperature/humidity sensor trouble
(HUD_M/TH_M)
64
Toner supply operation trouble (K)
70
Improper toner cartridge detection (K)
74
Toner cartridge CRUM error (K)
78
Image density registration sensor trouble
91
High density process control high voltage
error (K)
F3
12
Paper feed tray 1 lift up trouble
22
Paper feed tray 2 lift up trouble
F6
00
ICU-Fax communication trouble (ICU)
01
Fax EEPROM read/write error.
04
Fax modem operation trouble.
21
LIU & Fax soft switch error (combination)
30
Access error to 1-chip on Fax board.
F6
97
Fax Pwb compatibility trouble.
98
Improper Fax & Destination information.
H2
00
Thermistor open trouble (TH_UM).
01
Lower thermistor open trouble (TH_LM).
02
Thermistor open trouble (TH_US).
H3
00
Fuser high temperature trouble (TH_UM).
01
Fuser high temperature trouble (TH_LM).
02
Sub thermistor fusing section high
temperature (TH_US).
H4
00
Fuser low temperature (TH_UM)
02
Sub thermistor fusing section low
temperature (TH_US)
H5
01
5 continuous (POD1 not reach) jams
H7
10
Fuser low temperature recovery error
(TH_UM)
L1
00
Scanner feed trouble.
L3
00
Scanner return trouble.
L4
02
Paper feed motor trouble
03
Fusing motor trouble
04
DV motor trouble K
11
Shift motor trouble
31
Paper exit cooling fan (POFM1/2) trouble
32
Power source cooling fan trouble
34
LSU cooling fan trouble
35
Paper exit cooling fan 2 trouble
40
Ozone fan trouble
43
Paper exit cooling fan (POFM3) trouble
44
Ozone exhaust fan trouble
