SADDLE FINISHER
Overview
This includes the offset function that outputs sorted paper while staggering each set of
paper, the staple sort function that staples each set of prints, the saddle stitch function
that automatically staples the center of the sheets and folds the sheets in half, and the
paper folding function that folds paper in half.
To punch holes in printed paper, install an optional hole punch module.
Function names
Supplies
Saddle finisher maintenance
Function names
Staple compiler
This temporarily stacks paper to be stapled.
Output tray
Stapled and offset output is delivered to this tray.
The tray is slidable. Extend the tray for printing on large-size paper (12" x 18", 11" x 17", 8-1/2"
x 14", 8-1/2" x 13", A3W, A3 and B4 sizes).
Side cover
Open this cover to replace the staple cartridge or remove a staple jam.
Saddle stitch tray
Saddle-stitched output is delivered to this tray.
Top cover
Open this cover to remove a paper misfeed.
Front cover
Open this cover to replace the staple cartridge, remove a staple jam, or remove a paper misfeed.
Tap the name to make its details pop up.
