SADDLE FINISHER (LARGE STACKER)
Overview
This includes the offset function that outputs sorted paper while staggering each set of paper, the
staple sort function that staples each set of prints, the saddle stitch function that automatically
staples the center of the sheets and folds the sheets in half, and the paper folding function that
folds paper in half.
To punch holes in printed paper, install an optional hole punch module.
Function names
Supplies
Saddle finisher (large stacker) maintenance
Function names
Output trays (upper tray, lower tray)
Stapled and offset output is delivered to this tray.
The tray is slidable. Extend the tray for printing on large-size paper (12" x 18", 11" x 17", 8-1/2" x 14",
8-1/2" x 13", A3W, A3 and B4 sizes).
Saddle stitch tray guide
This guides the output as it is delivered to the tray. Before printing, attach the saddle stitch tray guide in the
appropriate position below for the paper size to be used.
Staple compiler
This temporarily stacks paper to be stapled.
Saddle stitch tray
This guides the output as it is delivered to the tray. Before printing, attach the saddle stitch tray guide in the
appropriate position below for the paper size to be used.
Top cover
Open this cover to remove a paper misfeed.
Front cover
Open this cover to replace the staple cartridge, remove a staple jam, or remove a paper misfeed.
Tap the name to make its details pop up.
