Sharp MX-M5050 Start Guide

SPECIFICATIONS
67
*1: Stand/550 sheet paper drawer (MX-DE25 N)
*2: Stand/2x550 sheet paper drawer (MX-DE26 N)
*3: Stand/3x550 sheet paper drawer (MX-DE27 N)
*4: Low stand/550 sheet paper drawer (MX-DE29 N)
Tray 2 / 3 / 4
Name Tray 2 Tray 2/3 Tray 2/3/4 Tray 2
(MX-DE25 N)
*1
(MX-DE26 N)
*2
(MX-DE27 N)
*3
(MX-DE29 N)
*4
Paper sizes 12" × 18" , 11" × 17", 8-1/2" × 14", 8-1/2" × 13-1/2",
8-1/2" × 13-2/5", 8-1/2" × 13", 8-1/2" × 11", 8-1/2" × 11"R,
7-1/4" × 10-1/2"R, 5-1/2" × 8-1/2"R, A3 wide, A3, B4, A4,
A4R, B5, B5R, A5R
Useable paper 16 lbs. bond to 110 lbs. Cover (60 g/m
2
to 300 g/m
2
)
Paper capacity 550 sheets 1100 (550 × 2) 1650 (550 × 3) 550 sheets
Required power
supply
Supplied from main machine
Dimensions MX-DE25N/DE26N/DE27N:
22-61/64" (W) × 25-19/32" (D) × 15-3/4" (H)
(583 mm (W) × 650 mm (D) × 400 mm (H))
MX-DE29 N:
22-61/64" (W) × 25-19/32" (D) × 8-9/32" (H)
(583 mm (W) × 650 mm (D) × 210 mm (H))
Weight
Approx. 39.7 lbs. Approx. 44.1 lbs. Approx. 55.1 lbs. Approx. 28.7 lbs.
(18 kg) (20 kg) (25 kg) (13 kg)
Stand/550&2100 sheet paper drawer
(Tray 2 / 3 / 4) / Large capacity tray (Tray 5)
Name Stand/550&2100 sheet paper drawer (MX-DE28 N)
Large capacity tray (MX-LC17 N)
Paper sizes
Tray 2: 12" × 18", 11" × 17", 8-1/2" × 14", 8-1/2" × 13-1/2",
8-1/2" × 13-2/5", 8-1/2" × 13", 8-1/2" × 11", 8-1/2" × 11"R, 7-1/4" ×
10-1/2"R, 5-1/2" × 8-1/2"R, A3 wide, A3, B4, A4, A4R, B5, B5R, A5R
Tray 3: 8-1/2" × 11", A4
Tray 4/5: 8-1/2" × 11", A4, B5
Useable paper Tray 2: 16 lbs. bond to 110 lbs. Cover (60 g/m
2
to 300 g/m
2
)
Tray 3/4: 16 lbs. bond to 28 lbs. bond (60 g/m
2
to 105 g/m
2
)
Tray 5: 16 lbs. bond to 80 lbs. Cover (60 g/m
2
to 220 g/m
2
)
Paper capacity Tray 2: 550 Tray 3: 1200
Tray 4: 900 Tray 5: 3000
Required power
supply
Supplied from main machine
Dimensions MX-DE28 N:22-61/64" (W) × 25-19/32" (D) × 15-3/4" (H)
(583 mm (W) × 650 mm (D) × 400 mm (H))
MX-LC17 N:14-49/64" (W) x 23-9/16" (D) x 17-41/64" (H)
(375 mm (W) x 598.4 mm (D) x 448 mm (H))
Weight MX-DE28 N: Approx. 66.1 lbs. (30 kg)
MX-LC17 N: Approx. 48.5 lbs. (22 kg)
Finisher (Stored in the machine)
Name Finisher (MX-FN27 N)
Paper sizes Depends on feeder specifications
Useable paper
Paper weight : 13 lbs. to 110 lbs. Cover (55 g/m
2
to 300 g/m
2
)
No. of trays 1+
Tray capacity
(13-20 lbs. (60-
80g/m
2
))
Non-stapled
12" × 18" , 11" × 17", 8-1/2" × 14" ( A3 wide, A3, B4): 250 sheets
8-1/2" × 11" , 8-1/2" × 11"R , 7-1/4" × 10-1/2"R , 5-1/2" ×
8-1/2"R (A4, A4R, B5, B5R, A5, A5R): 500 sheets
Staple function
11" × 17", 8-1/2" × 14" (A3, B4): 30 units or 250 sheets
8-1/2" × 11", 8-1/2" × 11"R (A4, A4R, B5): 30 units or 500 sheets
Stapleless staple function
11" × 17", 8-1/2" × 14", 8-1/2" × 11" (A3, B4, A4, B5): 30 units
• Offset output is not available for 12" × 18", 7-1/4" × 10-1/2"R,
5-1/2" × 8-1/2"R (A3 wide, B5R, A5, A5R).
Max. no. of
stapled sheets
(24 lbs. (90
g/m
2
))
Staple: Max. no. of 50 sheets (8-1/2" × 11", 8-1/2"
× 11"R (A4, A4R, B5))
Max. no. of 2 sheets (110 lbs. (300 g/m
2
))
+ 48 sheets (24 lbs. (90 g/m
2
))
Max. no. of 30 sheets (11" × 17", 8-1/2" ×
14" (A3, B4))
Stapleless staple: Max. no. of 5 sheets
(11" × 17", 8-1/2" × 11" (A3, B4, A4, B5))
Staple position 1 bottom, 1 top, 2 middle
Manual staple Staple position: 1 top
Max. no. of stapled sheets: 11/64" (4 mm) or less
Required power
supply
Supplied from main machine
Weight Approx. 26.5 lbs. (12 kg)
Dimensions When output paper tray is stored
21-1/32" (W) x 20-43/64" (D) x 7-61/64" (H)
(534 mm (W) x 525 mm (D) x 202 mm (H))
When output paper tray is extended
26-11/32" (W) x 20-43/64" (D) x 7-61/64" (H)
(669 mm (W) x 525 mm (D) x 202 mm (H))
