12
Name Saddle Stitch Finisher (MX-FN10)
Paper sizes Dependsonfeederspecications
Useable paper Paper weight 55 g/m
2
(13 lbs.) to 300 g/m
2
(110 lbs. Cover)
No. of trays 2 (Upper tray / Lower tray)
Tray capacity (80 g/m
2
(21
lbs.))
Upper tray
Non-stapled A3 wide (12" × 18") / A3 (11" × 17") /
B4 (8-1/2" × 14") / A5R (5-1/2" × 8-1/2"R): 500 sheets
A4 (8-1/2" × 11") / A4R (8-1/2" × 11"R) / B5 /
B5R (7-1/4" × 10-1/2"R): 1,000 sheets
Staple function A3 (11" × 17") / B4 (8-1/2" × 14"): 50 units or 500 sheets
A4 (8-1/2" × 11") / A4R (8-1/2" × 11"R) / B5 / B5R:
50 units or 1,000 sheets (For A4 (8-1/2" × 11"), B5, 50 sets
only when stapled in a single location on the far side)
Lower tray 10 units (11 to 15 sheets), 15 units (6 to 10 sheets),
20 units (1 to 5 sheets)
Offset output is not available for A3 wide (12" × 18") / A5R (5-1/2" × 8-1/2"R).
Required power supply Supplied from this machine
Weight Approx. 40 kg (88.2 lbs.)
Dimensions
When output paper tray is stored
497 mm (W) × 631 mm (D) × 988 mm (H)
(19-9/16" (W) × 24-27/32" (D) × 38-57/64" (H))
When output paper tray is extended
656 mm (W) × 631 mm (D) × 988 mm (H)
(25-53/64" (W) × 24-27/32" (D) × 38-57/64" (H))
Max. no. of stapled sheets
(90 g/m
2
(24 lbs.))
Max. no. of 50 sheets (A4 (8-1/2" × 11"), A4R (8-1/2" × 11"R), B5, B5R)
Max. no. of 25 sheets (A3 (11" × 17"), B4 (8-1/2" × 14"))
Staple position 1 bottom, 1 top, 2 middle
Staple method (for saddle stitch)
Centred fold with stapling in 2 centre places
Saddle stitch fold position Centred fold
Saddle usable sizes A3 (11" × 17") / B4 (8-1/2 × 14") / A4R (8-1/2" × 11"R)
Saddle usable paper weight
60 g/m
2
(16 lbs.) to 220 g/m
2
(80 lbs. Cover)
Paper weighting 106 g/m
2
(28 lbs.) to 220 g/m
2
(80 lbs. Cover) is only able to be
used in cover mode and for single sheet fold.
Max. no. of saddle-stitched
sheets
Max. no. of 15 sheets (80 g/m
2
(21 lbs.)):
14 sheets (80 g/m
2
(21 lbs.)) + 1 sheet (220 g/m
2
(80 lbs. Cover))
Max. no. of 10 sheets (90 g/m
2
(24 lbs.)):
9 sheets (90 g/m
2
(24 lbs.)) + 1 sheet (220 g/m
2
(80 lbs. Cover))
Name Finisher (MX-FN11)
Paper sizes Dependsonfeederspecications
Useable paper Paper weight 55 g/m
2
(13 lbs.) to 300 g/m
2
(110 lbs. Cover)
No. of trays 2 (Upper tray / Lower tray)
Tray capacity
(80g/m
2
(21 lbs. bond))
Upper tray
Non-stapled A3 wide (12" × 18") / A3 (11" × 17") / B4 (8-1/2" × 14") /
A4R (8-1/2" × 11"R) / B5R (7-1/4" × 10-1/2"R): 650 sheets
A5R (5-1/2" × 8-1/2"R): A4 (8-1/2" × 11") / B5: 1,550 sheets
Staple function A4 (8-1/2" × 11") / B5: 100 units or 1,550 sheets
A3 (11" × 17") / B4 (8-1/2" × 14") / A4R (8-1/2" × 11"R):
50 units or 650 sheets
Lower tray
Non-stapled A3 wide (12" × 18") / A3 (11" × 17") / B4 (8-1/2" × 14") /
A4R (8-1/2" × 11"R) / B5R (7-1/4" × 10-1/2"R): 650 sheets
A4 (8-1/2" × 11") / B5: 2,450 sheets
A5R (5-1/2" × 8-1/2"R): 1,700 sheets
Staple function A4 (8-1/2" × 11") / B5: 100 units or 1,550 sheets
A3 (11" × 17") / B4 (8-1/2" × 14") / A4R (8-1/2" × 11"R):
50 units or 650 sheets
Offset output is not available for A3 wide (12" × 18") / B5R (7-1/4" × 10-1/2"R) /
A5R (5-1/2" × 8-1/2"R).
Required power supply Supplied from this machine
Weight Approx. 45 kg (99 lbs.)
Dimensions
When output paper tray is stored
515 mm (W) × 645 mm (D) × 1100 mm (H)
(20-9/32" (W) × 25-25/64" (D) × 43-19/64" (H))
When output paper tray is extended
645 mm (W) × 645 mm (D) × 1100 mm (H)
(25-25/64" (W) × 25-25/64" (D) × 43-19/64" (H))
Max. no. of stapled sheets
(90 g/m
2
(24 lbs.))
Max. no. of 50 sheets (A4 (8-1/2" × 11"), B5)
Max. no. of 30 sheets (A3 (11" × 17"), B4 (8-1/2" × 14"), A4R (8-1/2" × 11"R))
Staple position 1 bottom, 1 top, 2 middle
Saddle stitch nisher
Name
Punch module for MX-FN17
MX-PN11A, MX-PN11B, MX-PN11C,
MX-PN11D
Punch module for MX-FN11
MX-PNX6A, MX-PNX6B, MX-PNX6C,
MX-PNX6D
Paper size for punch module A3 (11" × 17") to B5R (7-1/4" × 10-1/2"R)
Holes
MX-PN11A 2 holes, MX-PN11B 3 holes
MX-PN11C 4 holes, MX-PN11D 4 holes (wide)
MX-PNX6A 2 holes, MX-PNX6B 3 holes
MX-PNX6C 4 holes, MX-PNX6D 4 holes (wide)
Required power supply Supplied from Finisher
Dimensions
98 mm (W) × 477 mm (D) × 137 mm (H)
(3-55/64" (W) × 18-25/32" (D) × 5-13/32" (H))
115 mm (W) × 600 mm (D) × 995 mm (H)
(4-39/64" (W) × 24 (D) × 39-13/16" (H))
Weight Approx. 3 kg (6.6 lbs.) Approx. 8 kg (17.6 lbs.)
Finisher (large stacker)
Punch module (for nisher)
Name
Punch module for MX-FN18
MX-PNX6A, MX-PNX6B, MX-PNX6C,
MX-PNX6D
Punch module for MX-FN10
MX-PNX5A, MX-PNX5B, MX-PNX5C,
MX-PNX5D
Paper size for punch module A3 (11" × 17") to A4 (8-1/2" × 11")
Holes
MX-PNX6A 2 holes, MX-PNX6B 3 holes
MX-PNX6C 4 holes, MX-PNX6D 4 holes (wide)
MX-PNX5A 2 holes, MX-PNX5B 3 holes
MX-PNX5C 4 holes, MX-PNX5D 4 holes (wide)
Required power supply Suppliedfromsaddlenisher
Dimensions
115 mm (W) × 600 mm (D) × 995 mm (H)
(4-17/32" (W) × 23-5/8" (D) × 39-11/64" (H))
122 mm (W) × 604 mm (D) × 248 mm (H)
(4-13/16" (W) × 23-25/32" (D) × 9-49/64" (H))
Weight Approx. 8 kg (17.6 lbs.) Approx. 3.5 kg (7.7 lbs. or less)
Punch module (for saddle nisher)
