PART NAMES
1 Inlet (Air)
2 Open Panel
3 AUX. Button
4 Air Filters
5 Receiver Window
6 Louvre Unit
Open to clean the inside of the air
conditioner.
7 Indicator Panel
8 Vertical Adjustment Louvres
9 Horizontal Adjustment Louvres
0 Outlet (Air)
q Remote Control
w FULL POWER Lamp (green )
e SELF CLEAN Lamp (green )
r PLASMACLUSTER Lamp
(blue, green)
t TIMER Lamp (orange )
y OPERATION Lamp (red )
OUTDOOR UNIT
NOTE: Actual units might vary slightly from those shown above.
INDOOR UNIT
1
2
3
4
5
6
7
8
9
0
q
u Inlet(Air)
i Refrigerant Tube and
Interconnecting Cord
o Drainage Hose
p Outlet(Air)
4
w
e
r
t
y
u
i
o
p
