PN-L803C/80TC3 SERVICE MENU/VARIOUS SETTING TOOL OPERATING PROCEDURES 4- 51
9 Size Screen size
Described contents are the following six kinds of contents.
・Wide
・Zoom1
・Zoom2
・Normal
・DotbyDot
10 Color Mode Color mode
Described contents are the following four kinds of contents.
・Standard
・Vivid
・sRGB
・High Illuminance
11 Bright Brightness
Setting value from 0 to 31 is described.
12 Volume Volume
Setting value from 0 to 31 is described.
13 Input Signal Input signal
・1280 x 1024
・1080p 60Hz
etc
When there is no input signal, “space” is described.
14 Status Hardware error status
When there is no hardware error, OK is described. When there is hardware error, NG is described.
15 Status Code Describe the current hardware state and error records as the code.
When there is no hardware error, this is described as “0000 - 0000 - 0000 – 0000”.
When there is some hardware error, the following codes are described.
A. hardware observation result
The hardware error parts are divided by the bit as the following table shown ad described I n the hex.
Bit
0 SYSTEM POWER1
1 SYSTEM POWER2
2 SYSTEM POWER3
3 SYSTEM POWER4
4 SYSTEM POWER5
5 BACKLIGHT
6 TOUCH PANEL
7 - 10 Reserved
11 Low voltage abnormality
12 - 13 Reserved
14 Temperature sensor abnormality
15 Temperature abnormality
bit 0
Bit 15
Example
