PN-L803C/80TC3 OUTLINE OF THE PRODUCTS 1 - 14
4. SCREEN DISPLAY
4 – 1.DUAL SCREEN DISPLAY
It is possible to display two screens simultaneously.
Set this function with “PIP MODES” in the PIP/PbyP menu.
* The currently selected input signal is displayed on the main screen.
* The following combinations are available for display:
DisplayPort - D-SUB1, D-SUB2
HDMI1, HDMI2, HDMI3 - D-SUB1, D-SUB2
PIP
A sub screen is displayed inside a main screen.
PbyP
A main screen and a sub screen are displayed in a line.
PbyP2
Displays a main screen which measures 1280 pixels in the longest
direction and a sub screen in a line.
(MEMO)
• You might infringe on a copyright of the author which is protected by copyright law when you display the images of the computer screen
and television/VCR simultaneously for profit-making or to show the image to the public.
• The screen size for dual-screen display is the same as the screen size for single-screen display. The Dot by Dot screen is displayed in
NORMAL size except when it is set as the PIP main screen.
• When dual-screen display is selected, the SCREEN MOTION function is disabled.
• When dual-screen display is selected, the CONNECT AUTO INPUT SELECT function and NO SIGNAL AUTO INPUT SEL. function are
disabled.
• When dual-screen display is selected, the INPUT SELECT options cannot be set.
• When dual-screen display is selected, the AUDIO menu cannot be set.
• When an interlaced signal (1080i, 480i, video) is input to the sub screen, horizontal lines may flicker. If this happens, display the image
on the main screen.
• Touch operation cannot be used in the sub screen.
