Sharp PN-80TC3 Service Manual

PN-L803C/80TC3 HARDWARE DESCRIPTIONS 8 - 13
CN No. No. Function
CN202 Touch Sensor Module
54 AFE B93
55 AFE B92
56 AFE B91
57 AFE B90
58 AFE B89
59 AFE B88
60 AFE B87
61 AFE B86
62 AFE B85
63 AFE B84
64 AFE B83
65 AFE B82
66 AFE B81
67 AFE B80
68 AFE B79
69 AFE B78
70 AFE B77
71 AFE B76
72 AFE B75
73 AFE B74
74 AFE B73
75 AFE B72
76 AFE B71
77 Dummy
78 GND
79 GND
80 GND
■
AFE PWB
CN No. No. Function
CN101 X1206 PWB (LVDS
Input/Output)
1 +5V
2 +5V
3 +5V
4 +5V
5 GND
6 GND
7 GND
8 GND
9 GND
10 AFE I2C SDA
11 AFE I2C SCL
12 GND
13 AFE2 SLEEP
14 AFE2 RESETN
15 GND
16 AFE2 DATA2N
17 AFE2 DATA2P
18 AFE2 DATA1N
19 AFE2 DATA1P
20 AFE2 DATA0N
21 AFE2 DATA0P
22 AFE2 CTRLN
CN101 X1206 PWB (LVDS
Input/Output)
23 AFE2 CTRLP
24 AFE2 CLKN
25 AFE2 CLKP
26 GND
27 GND
28 AFE SLEEP
29 AFE RESETN
30 GND
31 AFE DATA2N
32 AFE DATA2P
33 AFE DATA1N
34 AFE DATA1P
35 AFE DATA0N
36 AFE DATA0P
37 AFE CTRLN
38 AFE CTRLP
39 AFE CLKN
40 AFE CLKP
41 GND
CN201 Touch Sensor Module
1 GND
2 GND
3 GND
4 GND
5 DUMMY
6 AFE1 B70
7 AFE1 B69
8 AFE1 B68
9 AFE1 B67
10 AFE1 B66
11 AFE1 B65
12 AFE1 B64
13 AFE1 B63
14 AFE1 B62
15 AFE1 B61
16 AFE1 B60
17 AFE1 B59
18 AFE1 B58
19 AFE1 B57
20 AFE1 B56
21 AFE1 B55
22 AFE1 B54
23 AFE1 B53
24 AFE1 B52
25 AFE1 B51
26 AFE1 B50
27 AFE1 B49
28 AFE1 B48
29 AFE1 B47
30 AFE1 B46
31 AFE1 B45
32 AFE1 B44
33 AFE1 B43
34 AFE1 B42
35 AFE1 B41
