Sharp PN-80TC3 Service Manual

PN-L803C/80TC3 HARDWARE DESCRIPTIONS 8 - 16
CN No. No. Function
CN302 Touch Sensor Module
11 AFE2 B136
12 AFE2 B135
13 AFE2 B134
14 AFE2 B133
15 AFE2 B132
16 AFE2 B131
17 AFE2 B130
18 AFE2 B129
19 AFE2 B128
20 AFE2 B127
21 AFE2 B126
22 AFE2 B125
23 AFE2 B124
24 AFE2 B123
25 AFE2 B122
26 AFE2 B121
27 AFE2 B120
28 AFE2 B119
29 AFE2 B118
30 AFE2 B117
31 AFE2 B116
32 AFE2 B115
33 AFE2 B114
34 AFE2 B113
35 AFE2 B112
36 AFE2 B111
37 AFE2 B110
38 AFE2 B109
39 AFE2 B108
40 AFE2 B107
41 AFE2 B106
42 AFE2 B105
43 AFE2 B104
44 AFE2 B103
45 AFE2 B102
46 AFE2 B101
47 AFE2 B100
48 AFE2 B99
49 AFE2 B98
50 AFE2 B97
51 AFE2 B96
52 AFE2 B95
53 AFE2 B94
54 AFE2 B93
55 AFE2 B92
56 AFE2 B91
57 AFE2 B90
58 AFE2 B89
59 AFE2 B88
60 AFE2 B87
61 AFE2 B86
62 AFE2 B85
63 AFE2 B84
64 AFE2 B83
CN302 Touch Sensor Module
65 AFE2 B82
66 AFE2 B81
67 AFE2 B80
68 AFE2 B79
69 AFE2 B78
70 AFE2 B77
71 AFE2 B76
72 AFE2 B75
73 AFE2 B74
74 AFE2 B73
75 AFE2 B72
76 AFE2 B71
77 DUMMY2
78 GND
79 GND
80 GND
■
Key PWB
CN No. No. Function
CN102
Key Connector
1 GND
2 3.3V
3 IR
4 SEL_IO
5 INIT_Done
6 Key2(Menu Key)
7 Key3(Power Key)
8 LED-G
9 LED-R
10 GND
