PN-L703A/L703B, PN-70TA3/70TB3, PN-L603A/L603B, PN-60TA3/60TB3
SERVICE MENU/VARIOUS SETTING TOOL OPERATING PROCEDURES 4 - 2
1-2．SERVICE MENU 2
AGING
AGING -> See "2. AGING"
CALIBRATION
Auto adjust GAIN and OFFSET only for
D-SUB[COMPONENT] and D-SUB[VIDEO].
-> See "3. CALIBRATION"
FACTORY RESET
Reset USAGE TIME and OPERATION LOG etc
in addition to USER ADJUSTMENT VALUE.
-> See "4．FACTORY RESET"
MODEL TYPE Switching of the destination:
JP : Mode l for Japan
US：Model for North America
EU：Model for Europe
CH:Model for CHina
When the destination is changed, the model
name is changed. JP and US are the same
model name. EU and CN are the same model
name.
HARDWARE
CHECK
Show the hardware check result.
Switch ON/OFF the settings of the hardware
check and the display of the hardware check
result.
-> See "*.Hardware check".
WHITE BALANCE
SETTING
-> See "8. How to Adjust White Balance "
-> See "8. How to Use White Balance "
EDID UPDATE
Update the EDID to the latest version.
-> See "* How to update the EDID."
GAMMA SETTING
Set the Gamma settings.
-> See "8. How to Adjust Gamma settings "
-> See "8. How to Use Gamma setting tool "
AUTO INPUT
CHANGE DELAY
Do not change these settings.
SIGNAL TUNING
LED DRIVER DC
1) Select "SERVICE2" with [VOL -()] key while displaying
“SERVICE MENU1” screen. Press [ENTER] key.
2）Select the setting item with [VOL + ()], [VOL - ()] keys.
3）Make adjustment with [BRIGHT - ( )],[BRIGHT + ()] keys.
As for items with => mark, press [ENTER] key to go on to the
next screen.
4）Press [MENU] key to exit.
1-3. SERVICE MENU 3
MODEL NAME SETTING Set the model name.
S/N SETTING Set the serial number.
USAGE TIME SETTING Set the usage time.
SYSTEM LOG INITIALIZE Initialize the system log.
TEMP LOG INITIALIZE Initialize the temperature log.
SAVE LOG Save the system log to the USB flash
drive.
SAVE/RESTORE
SETTINGS VALUE
Save or restore the user settings to the
USB flash drive.
POWER OFF COUNT Set the display time of the power off
confirmation screen which is displayed
when the main power is turned off.
1 ) With “SERVICE MENU1” display.
Select “SERVICE3” with [VOL - ()] button and press [BRIGHT+
()] button.
SERVICE1
SERVICE2
SERVICE3
MODEL NAME SETTING =>
SERVICE MENU3 1/1
USAGE TIME SETTING =>
SYSTEM LOG INITIALIZE =>
TEMP LOG INITIALIZE =>
SAVE/RESTORE SETTINGS VALUE =>
S/N SETTING =>
SAVE LOG =>
END [RETURN]
OK
[ENTER]
POWER OFF COUNT =>
2 ) Select setting item with [VOL+()] [VOL- ()] button.
3 ) Press [BRIGHT+ ()] button and advances to the next screen.
4 ) Press [MENU] button to return to the previous screen
sequentially, terminating the operation.
SERVICE1
SERVICE2
SERVICE3
AGING =>
SERVICE MENU2 1/2
FACTORY RESET =>
MODEL TYPE XX
HARDWARE CHECK =>
EDID UPDATE =>
CALIBRATION
WHITE BALANCE SETTING =>
END [RETURN]
GAMMA SETTING =>
OK [ENTER]
To Next Page
