Function Command Direction Parameter Reply Control/Response contents *
PIP MODES MWIN WR 0-3 0-3 0: OFF, 1: PIP, 2: PbyP, 3: PbyP2
○
PIP SIZE MPSZ WR 1-64 1-64
PIP POS THE LONGEST
DIRECTION
MHPS W 0-100
R 0-100
THE SHORTEST
DIRECTION
MVPS W 0-100
R 0-100
PIP POS LD+SD BATCH MPOS W 0-100,0-100 Specify the position in MPOSxxxyyy format.
(xxx: Longer side, yyy: Shorter side position)
R 0-100,0-100 Returns a response in (xxx,yyy) format.
(xxx: Longer side, yyy: Shorter side position)
PIP BLEND MWBL WR 0-15 0-15
PIP SOURCE MWIP WR 1 1 DVI-I
2 2 D-SUB[RGB]
3 3 D-SUB[COMPONENT]
4 4 D-SUB[VIDEO]
9 9 HDMI1[AV]
10 10 HDMI1[PC]
12 12 HDMI2[AV]
13 13 HDMI2[PC]
14 14 DisplayPort
SOUND CHANGE MWAD WR 1-2 1-2 1: MAIN, 2: SUB
MAIN POS (Main screen) MWPP WR 0-1 0-1 0: POS1, 1: POS2
PbyP2 POS (Sub screen) MW2P WR 0-2 0-2 0: POS1, 1: POS2, 2: POS3
AUTO OFF MOFF WR 0-1 0-1 0: MANUAL, 1: AUTO
OTHERS menu
Function Command Direction Parameter Reply Control/Response contents *
SCREEN MOTION PATTERN SCSV WR 0-4 0-4 0: OFF, 1-4: PATTERN1-4
○
MOTION TIME1 MTIM WR 0-20 0-20
MOTION TIME2
(PATTERN1)
MINT WR 10-990 10-990 Per 10 seconds
MOTION TIME2
(PATTERN2-4)
MINT WR 5-20 5-20 Per second
POWER MANAGEMENT (PC) PMNG WR 0-1 0-1 0: OFF, 1: ON
POWER MANAGEMENT (AV) PMAV WR 0-1 0-1 0: OFF, 1: ON
AUTO INPUT CHANGE AINC WR 0-1 0-1 0: OFF, 1: ON
LOGO SCREEN BTSC WR 0-1 0-1 0: OFF, 1: ON
INPUT
RESOLUTION
(PC)
RESOLUTION CHECK PXCK R - Returns current resolution in the form of hhh, vvv.
-
PIXEL SETTING
(D-SUB[RGB],
DVI-I(analog))
PXSL WR 1 1 768) 1360 x 768
2 2 768) 1280 x 768
3 3 768) 1024 x 768
5 5 480) 848 x 480
6 6 480) 640 x 480
7 7 1050) 1680 x 1050
8 8 1050) 1400 x 1050
9 9 768) AUTO
10 10 480) AUTO
INPUT RESOLUTION (AV) RESOLUTION CHECK RESO R - 480i, 480p, 1080i, 720p, 1080p, VGA , etc.
ZOOM2 SPECIAL SETTING
(D-SUB[RGB], DVI-I(analog))
Z2SP WR 0-1 0-1 0: OFF, 1: ON
○
SCAN MODE SCAN WR 0-2 0-2 0: MODE1, 1: MODE2, 2: MODE3 (When the input mode is AV)
COLOR SYSTEM CSYS WR 0-5 0-5 0: AUTO, 1: PAL, 2: PAL-60, 3: SECAM, 4: NTSC3.58, 5: NTSC4.43
