PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
QT-CD210/C
– 1 –
INTEGRATED CIRCUITS
IC1 VHITA2111N/-1 J AN FM/AM IF MPX.,TA2111N
IC101 VHIBA3311L/-1 J AK REC./P.B.Equalizer Amp.,
BA3311L
IC201 VHITA8227P/-1 J AH Power Amp.,TA8227P
IC801 VHITA2109F/-1 J AL Servo Pre Amp.,TA2109F
IC802 VHITC9457F0-1 J AZ Servo/Signal Control,TC9457F0
IC803 VHILA6541D/-1 J AW Focus/Tracking/Spin/Sled Driver,
LA6541D
TRANSISTORS
Q204 VSKTA1046Y/-1 J AC Sillicon,PNP,KTA1046 Y
Q205 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q351 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
Q801 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q802 VSKTA1273Y/-1 J AE Silicon,PNP,KTA1273 Y
Q803 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
DIODES
D1,2 VHD1N4148//-1 J AA Silicon,1N4148
D101,102 VHD1N4148//-1 J AA Silicon,1N4148
D201~203 VHD1N4148//-1 J AA Silicon,1N4148
D651~654 VHD1N4004//-1 J AB Silicon,1N4004
D801 VHD1N4004//-1 J AB Silicon,1N4004
ZD201 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1BSB
FILTERS
CF1 RFILF0001SJZZ J AD FM IF,10.7 MHz
CF3 RFILA0001SJZZ J AD AM IF,460 kHz
F1 RFILR0001SJZZ J AD FM Band Pass Filter
TRANSFORMERS
T2 RCILI0006SJZZ J AC FM Detection
T3 RCILI0007SJZZ J AC AM IF
! T651 RTRNP0036SJZZ J AQ Power
COILS
COR1 RCORF0005SJZZ J AB Core
L1 RCILR0001SJZZ J AB FM RF
L2 RCILB0004SJZZ J AD FM Oscillation
L3 RCILA0001SJZZ J AD AM Bar Antenna
L4 RCILB0002SJZZ J AC AM Oscillation
L301 RCILB0003SJZZ J AD Bias Oscillation
L801 VP-DHR82K0000 J AE 0.82 µH,Choke
VARIABLE RESISTOR
VR201 RVR-B0001SJZZ J AE 20 kohms (B),Semi-VR [Volume]
VARIABLE CAPACITORS
VC1~4 RVC-R0001SJZZ J AK Variable Capacitor with Trimmer
(TC1~4)
VIBRATOR
X801 RCRM-0002SJZZ J AE Ceramic,16.93 MHz
CAPACITORS
C1 VCKYPA1HF223Z J AB 0.022 µF,50V
C2 VCCCPA1HH180J J AA 18 pF (CH),50V
C3 VCCUPA1HJ220J J AA 22 pF (UJ),50V
C4 VCCCPA1HH4R0C J AA 4 pF (CH),50V
C6 VCKYPA1HB331K J AA 330 pF,50V
C7 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C8,9 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C10 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C11 RC-GZA474AF1H J AA 0.47 µF,50V,Electrolytic
C12 RC-GZA475AF1H J AB 4.7 µF,50V,Electrolytic
C13 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C14 VCKYPA1HF223Z J AB 0.022 µF,50V
C15 VCCCPA1HH100J J AA 10 pF (CH),50V
C16,17 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C18,19 VCQYKA1HM153K J AB 0.015 µF,50V,Mylar
C20 VCKYPA1HF473Z J AB 0.047 µF,50V
C21 VCCCPA1HH2R0C J AA 2 pF (CH),50V
C22 RC-GZA104AF1H J AB 0.1 µF,50V,Electrolytic
C105,106 VCKYPA1HB272K J AA 0.0027 µF,50V
C107,108 VCKYPA1HB821K J AA 820 pF,50V
C109,110 VCKYPA1HB271K J AA 270 pF,50V
C111,112 VCKYPA1HB331K J AA 330 pF,50V
C113,114 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C115,116 VCQYKA1HM183K J AB 0.018 µF,50V,Mylar
C117,118 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C119 RC-GZA225AF1H J AB 2.2 µF,50V,Electrolytic
C120 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C121,122 VCKYPA1HF103Z J AB 0.01 µF,16V
C123 RC-GZA227AF1A J AB 220 µF,10V,Electrolytic
C202 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C203 VCKYPA1HF103Z J AB 0.01 µF,16V
C204 VCKYPA1HF223Z J AB 0.022 µF,50V
C215,216 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C217,218 VCKYPA1HB152K J AA 0.0015 µF,50V
C219,220 RC-GZA105AF1H J AB 1 µF,50V,Electrolytic
C221,222 VCKYPA1HB102K J AA 0.001 µF,50V
C225 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C226 VCKYPA1HF223Z J AB 0.022 µF,50V
C227 RC-GZW338AF1C J AF 3300 µF,16V,Electrolytic
C233,234 RC-GZA477AF1A J AC 470 µF,10V,Electrolytic
C235~238 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C239,240 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C241 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C351 VCQYKA1HM222K J AA 0.0022 µF,50V,Mylar
C352 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C353 VCQYKA1HM562K J AA 0.0056 µF,50V,Mylar
C354 VCQYKA1HM223K J AB 0.022 µF,50V,Mylar
C651~654 VCKYPA1HF223Z J AB 0.022 µF,50V
C801 VCKYPA1HF103Z J AB 0.01 µF,16V
C802 VCKYPA1HF223Z J AB 0.022 µF,50V
C804 VCCCPA1HH2R0C J AA 2 pF (CH),50V
C805 VCKYPA1HF223Z J AB 0.022 µF,50V
C806 RC-GZA337AF1C J AC 330 µF,16V,Electrolytic
C807 VCKYPA1HF473Z J AB 0.047 µF,50V
C813 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C814 VCKYPA1HF473Z J AB 0.047 µF,50V
C815 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C816 VCKYPA1HF223Z J AB 0.022 µF,50V
C817 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C818 VCCSPA1HL560J J AA 56 pF,50V
C819,820 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C821 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C822 VCKYPA1HF473Z J AB 0.047 µF,50V
C823,824 VCKYPA1HF223Z J AB 0.022 µF,50V
C825 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C826 VCCSPA1HL470J J AA 47 pF,50V
C827 VCQYKA1HM153K J AB 0.015 µF,50V,Mylar
C828 VCKYPA1HB272K J AA 0.0027 µF,50V
C829 VCKYPA1HB472K J AB 0.0047 µF,50V
C830 VCQYKA1HM103K J AA 0.01 µF,50V,Mylar
C832 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C833 VCQYKA1HM333K J AB 0.033 µF,50V,Mylar
C834,835 VCKYPA1HB471K J AA 470 pF,50V
C836~839 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C840~842 VCKYPA1HF473Z J AB 0.047 µF,50V
C843 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
C844 RC-GZA107AF1A J AB 100 µF,10V,Electrolytic
C845 VCKYPA1HF473Z J AB 0.047 µF,50V
C846 RC-GZA106AF1C J AB 10 µF,16V,Electrolytic
C847,848 RC-GZA226AF1C J AB 22 µF,16V,Electrolytic
C849,850 VCKYPA1HB222K J AA 0.0022 µF,50V
C851,852 RC-GZA335AF1H J AB 3.3 µF,50V,Electrolytic
C853 VCKYPA1HF223Z J AB 0.022 µF,50V
C854 VCKYPA1HB682K J AB 0.0068 µF,50V
C855 VCKYPA1HF223Z J AB 0.022 µF,50V
C856 VCKYPA1HB102K J AA 0.001 µF,50V
C863 RC-GZA476AF1C J AB 47 µF,16V,Electrolytic
RESISTORS
R1 VRD-ST2CD331J J AA 330 ohms,1/6W
R2 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R3 VRD-ST2CD224J J AA 220 kohms,1/6W
R4 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R5 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R6 VRD-ST2CD101J J AA 100 ohm,1/6W
R7 VRD-ST2CD121J J AA 120 ohms,1/6W
R8,9 VRD-ST2CD103J J AA 10 kohm,1/6W
