NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
QT-CD210/C
R10,11 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R101,102 VRD-ST2CD151J J AA 150 ohms,1/6W
R103,104 VRD-ST2CD123J J AA 12 kohms,1/6W
R105,106 VRD-ST2CD103J J AA 10 kohm,1/6W
R107,108 VRD-ST2CD102J J AA 1 kohm,1/6W
R109,110 VRD-ST2CD121J J AA 120 ohms,1/6W
R113,114 VRD-ST2CD822J J AA 8.2 kohms,1/6W
R115~118 VRD-ST2CD392J J AA 3.9 kohms,1/6W
R119,120 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R121,122 VRD-ST2CD182J J AA 1.8 kohms,1/6W
R123,124 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R125 VRD-ST2CD684J J AA 680 kohms,1/6W
R126 VRD-ST2CD101J J AA 100 ohm,1/6W
R201 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R202 VRD-ST2CD472J J AA 4.7 kohms,1/6W
R203 VRD-ST2CD561J J AA 560 ohms,1/6W
R215,216 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R219,220 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R221,222 VRD-ST2CD102J J AA 1 kohm,1/6W
R230 VRD-ST2EE2R7J J AA 2.7 ohms,1/4W
R231,232 VRD-ST2CD121J J AA 120 ohms,1/6W
R351 VRD-ST2CD101J J AA 100 ohm,1/6W
R352 VRD-ST2CD151J J AA 150 ohms,1/6W
R353 VRD-ST2CD333J J AA 33 kohms,1/6W
R354 VRD-ST2CD4R7J J AA 4.7 ohms,1/6W
R455,456 VRD-ST2CD153J J AA 15 kohms,1/6W
R457,458 VRD-ST2CD102J J AA 1 kohm,1/6W
R801 VRD-ST2EE220J J AA 22 ohms,1/4W
R802 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R803 VRD-ST2CD823J J AA 82 kohms,1/6W
R804 VRD-ST2CD683J J AA 68 kohms,1/6W
R805 VRD-ST2CD393J J AA 39 kohms,1/6W
R806 VRD-ST2CD272J J AA 2.7 kohms,1/6W
R807 VRD-ST2CD102J J AA 1 kohm,1/6W
R811 VRD-ST2CD223J J AA 22 kohms,1/6W
R812 VRD-ST2CD102J J AA 1 kohm,1/6W
R820 VRD-ST2CD473J J AA 47 kohms,1/6W
R821 VRD-ST2CD223J J AA 22 kohms,1/6W
R824 VRD-ST2CD103J J AA 10 kohm,1/6W
R826 VRD-ST2CD224J J AA 220 kohms,1/6W
R827 VRD-ST2CD153J J AA 15 kohms,1/6W
R828 VRD-ST2CD103J J AA 10 kohm,1/6W
R829 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R830 VRD-ST2CD103J J AA 10 kohm,1/6W
R831~834 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R835,836 VRD-ST2CD271J J AA 270 ohms,1/6W
R837,838 VRD-ST2CD103J J AA 10 kohm,1/6W
R839 VRD-ST2CD473J J AA 47 kohms,1/6W
R840 VRD-ST2EE100J J AA 10 ohm,1/4W
R843,844 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R846 VRD-ST2CD331J J AA 330 ohms,1/6W
R847 VRD-ST2CD102J J AA 1 kohm,1/6W
R848 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R849 VRD-ST2CD682J J AA 6.8 kohms,1/6W
R850 VRD-ST2CD152J J AA 1.5 kohms,1/6W
R851~853 VRD-ST2CD222J J AA 2.2 kohms,1/6W
R860 VRD-ST2CD101J J AA 100 ohm,1/6W
R861 VRD-ST2CD332J J AA 3.3 kohms,1/6W
R862 VRD-ST2CD223J J AA 22 kohms,1/6W
OTHER CIRCUITRY PARTS
BI801/CNS801 QCNWN0158SJZZ J AF Connector Ass’y,8/8Pin
BI802/CNS802 QCNWN0159SJZZ J AD Connector Ass’y,5/5Pin
BI803/CNS803 QCNWN0115SJZZ J AE Connector Ass’y,6/6Pin
CNP101 QCNCW001DSJZZ J AC Plug,4Pin
CNP201 QCNCW001CSJZZ J AC Plug,3Pin
CNP602 QCNCW002BSJZZ J AC Plug,2Pin
CNP803 QCNCM932FAFZZ J AC Plug,6Pin
CNS101 QCNWN0010SJZZ J AG Connector Ass’y,4Pin
CNS201 QCNWN0157SJZZ J AC Connector Ass’y,3Pin
CNS602 QCNWN0162SJZZ J AC Connector Ass’y,2Pin
FW806 QCNWN0163SJZZ J AD Flat Wire,10Pin
LCD801 RV-LX0006SJZZ J AF LCD Display
M601(240-6) 9GD192112346 J AX Motor with Pulley [Tape]
M701 RMOTV0409AFM1 J AN Motor with Gear [Sled]
M702 RMOTV0408AFM3 J AN Motor with Chassis [Spindle]
! SO651 QSOCA0001SJZZ J AE AC Inlet Socket [QT-CD210/C]
! SO651 QSOCA0005SJZZ J AC Inlet Socket [QT-CD210C]
SP201,202 VSPA010PB014S J AG Speaker,Woofer
SW102 QSW-S0001SJZZ J AD Switch,Slide Type
[Record/Playback]
SW201 QSW-S0002SJZZ J AD Switch,Slide Type
[Function Selector]
SW601(240-7) 9GD640101149 J Switch,Leaf Type [Tape Main]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
SW801 QSW-K0001SJZZ J AC Switch,Key Type [Play/Pause]
SW802 QSW-K0001SJZZ J AC Switch,Key Type [Stop]
SW803 QSW-K0001SJZZ J AC Switch,Key Type [Review/Down]
SW804 QSW-K0001SJZZ J AC Switch,Key Type [Cue/Up]
SW810 QSW-F0001SJZZ J AD Switch,Leaf [CD Lid]
CD MECHANISM PARTS
301 NGERH0586AFZZ J AC Gear,Middle
302 NGERH0587AFZZ J AC Gear,Drive
303 MLEVP1054AFZZ J AC Rail,Guide
304 NSFTM0291AFFW J AD Shaft,Guide
305 PCUSG0613AFZZ J AC Cushion
! 306 DCTRH8003SJ01 J Pickup Unit Ass’y
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M701 RMOTV0409AFM1 J AN Motor with Gear [Sled]
M702 RMOTV0408AFM3 J AN Motor with Chassis [Spindle]
SW702 QSW-F9001AWZZ J AE Switch,Push Type [Pickup In]
CABINET PARTS
201 GCABA1038SJM1 J AV Front Cabinet
202 GCABB1038SJSA J AN Top Cabinet
203 GFTAT1004SJSA J AF CD Lid
204 CHLDM1001SJ01 J AG Stabilizer Ass’y
204- 1 PMAGF0002AWZZ J AE Magnet
204- 2 ———— — Holder,Stabilizer
(Not Replacement Item)
205 GFTAB1009SJSA J AC Battery Compartment Lid
206 GFTAC1004SJSA J AE Cassette Holder
208 HDECQ0027SJSA J AB Decoration Plate,Dial Window
209 HPNLC1042SJSA J AC Panel,Control
210 HSSND0001SJSA J AB Dial Pointer
211 JBTN-0013SJSA J AB Button,Pause
212 JBTN-0014SJSA J AB Button,Stop/Eject
213 JBTN-0015SJSA J AB Button,Fast Forward
214 JBTN-0016SJSA J AB Button,Rewind
215 JBTN-0017SJSA J AB Button,Play
216 JBTN-0018SJSA J AB Button,Record
217 JHNDP1003SJSA J AE Handle
218 JKNBK0023SJSA J AB Knob,Volume
219 JKNBK0024SJSA J AB Button,Function
220 JKNBZ0031SJSA J AD Button,CD
221 JKNBZ0032SJSA J AC Knob,Tuning
222 CGERH0001SJ01 J AF Damper Gear Ass’y
223 LANGK0001SJFW J AC Bracket,Button
224 LANGZ0003SJZZ J AE Bracket,Battery
225 LHLDA1001SJZZ J AC Holder,AM Bar Antenna
226 LHLDW1001SJZZ J AD Nylon Band
227 RCORF0002SJZZ J AC Core
228 LHLDZ1021SJZZ J Holder,LCD
229 MSPRC0004SJFN J Spring,Battery,-
230 MSPRC0005SJFD J AB Spring,Battery,+/-
231 MSPRD0002SJFD J AC Spring,CD Lid
232 MSPRD0009SJFD J AB Spring,Cassette Holder Up
233 MSPRZ0002SJFD J AB Spring,Rod Antenna
234 NDRM-0003SJZZ J AB Drum
235 PGUMS0001SJZZ J AB Cushion,CD Lid
236 PSLDM3003SJFW J Bracket,Shield
237 QANTR0003SJZZ J AL Rod Antenna
238 MSPRP0002SJFW J AC Bracket,Record
240 CMECB0003SJ01 J AZ Tape Mechanism Ass’y
240- 1 9GD192104309 J AR Pinch Roller Arm Ass’y
240- 2 9GD19210703 J AE Belt,REW/FF
240- 3 9GD19210938 J Belt,Main
240- 4 9GD62140116 J AT Head,Record/Playback
240- 5 9GD62071008 J AQ Head,Erase
240- 5 9GD62091010 J AM Head,Erase
240- 6(M601) 9GD192112346 J AX Motor with Pulley [Tape]
240- 7(SW601) 9GD640101149 J Switch,Leaf Type [Tape Main]
601 XBBSD25P06000 J AB Screw,ø2.5×6mm
602 XUBSD25P10000 J AB Screw,ø2.5×10mm
603 XUBSD30P08000 J AA Screw,ø3×8mm
604 XUBSD30P10000 J AA Screw,ø3×10mm
605 XUBSD30P12000 J AA Screw,ø3×12mm
– 2 –
