Sharp R-15AT Service Manual

R-15AT
35
∆
∆
∆
∆
∆
∆
∆
∆
∆
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
R32 VRD-B12EF272J Resistor 2.7k ohm 1/4W 1 AA
R33 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R40 VRD-B12EF272J Resistor 2.7k ohm 1/4W 1 AA
R50-58 VRD-B12EF101J Resistor 100 ohm 1/4W 9 AA
R70-71 VRD-B12EF472J Resistor 4.7 ohm 1/4W 2 AA
R80-88 VRD-B12EF472J Resistor 4.7 ohm 1/4W 9 AA
R90 VRS-B13AA101J Resistor 100 ohm 1W 1 AA
RY2 RRLY-A092DRE0 Relay (VRB18SP) 1 AL
RY3 RRLY-A093DRE0 Relay (VRB18) 1 AL
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA131DRE0 Touch control transformer 1 AR
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD2 VHEHZ4A2///-1 Zener diode (HZ4A2) 1 AA
ZD3 VHEHZ201///-1 Zener diode (HZ20-1) 1 AA
3- 2 FPNLCB773WRKZ Control panel frame with key unit 1 BA
3- 2-1 FUNTKB146WREZ Key unit 1 AW
3- 2-2 GCOVAA260WRP0 C/P case 1 BA
3- 2-3 GMADIA109WRF0 Display window 1 AE
3- 3 XEPSD30P08XS0 Screw; 3mm x 8mm 6 AA
OVEN PARTS
4- 1 FGLSPA062WRE0 Ceramic shelf 1 BL
4- 2 DOVN-A514WRY0 Oven cavity 1 BU
4- 3 MLEVPA227WRF0 Latch switch lever A 1 AF
4- 4 MLEVPA228WRF0 Latch switch lever B 1 AF
4- 5 MLEVPA229WRF0 Latch switch lever C 1 AF
4- 6 MSPRCA108WRE0 Latch lever spring 3 AC
4- 7 MSPRTA191WRE0 Switch lever B spring 1 AC
4- 8 PHOK-A121WRFZ Latch hook 1 AG
4- 9 FDUC-A362WRYZ Steam duct sub assembly 1 BB
4-10 PSKR-A351WRP0 Steam guide 1 AY
4-11 LBNDKA139WRW0 HV capacitor holder 1 AR
4-12 NFANJA029WRE0 Fan blade 1 AK
4-13 PDUC-A697WRF0 Fan duct 1 AM
4-14 FPLT-A007WRY0 Stirrer antenna assembly 1 BB
4-15 PCUSUA507WRP0 Cushion 1 AC
4-16 PCUSGA378WRP0 Cushion 1 AL
4-17 PSPA-A112WRE0 Mica washer 1 AC
4-18 LANGFA199WRWZ Chassis support 1 AH
4-19 NSFTPA035WRFZ Antenna motor shaft 1 AQ
4-20 PSKR-A359WRW0 Air guide 1 AM
4-21 PSKR-A349WRP0 Steam duct barrier 1 AF
4-22 PFILWA060WRP0 Lamp filter 1 AD
4-23 PDUC-A722WRF0 Air intake duct 1 AF
4-24 PCUSGA249WRP0 Cushion 1 AA
4-25 PCUSUA235WRP0 Cushion 1 AE
4-26 PCUSUA511WRP0 Cushion 2 AC
4-27 PCUSUA329WRP0 Cushion 1 AC
4-28 PCUSUA514WRP0 Cushion 1 AB
4-29 PPACGA171WRE0 Cushion 1 AK
4-30 PCUSUA515WRP0 Cushion 1 AD
4-31 PSHEPA668WRE0 Cover 1 AK
4-32 PCLICA034WRE0 Hand clip 3 AD
4-33 PSHEPA673WRE0 S/Film 1 AD
4-34 GLEGPA056WRE0 Leg 1 AD
4-35 LANGQA556WRMZ Earth angle 1 AL
DOOR PARTS
5- 1 FDORFA322WRT0 Door panel assembly 1 AZ
5- 2 PSHEPA649WRE0 Sealer film 1 AB
5- 3 FANGKA206WRY0 Latch angle assembly 1 AW
5- 4 FCOV-A005WRKZ Door case assembly 1 BH
5-4-1 LSTPPA180WRF0 Glass stopper R 1 AK
5-4-2 LSTPPA182WRF0 Glass stopper U 1 AN
5-4-3 PGLSPA522WRE0 Front door glass 1 AQ
5-4-4 XCPSD40P08000 Screw : 4mm x 8mm 6 AA
5-4-5 PSLDMA198WREZ Sealer plate 1 BB
5- 5 GWAKPA580WRM0 Door handle 1 AQ
5- 6 JHNDMA040WRW0 Handle lever 1 AN
5- 7 LANGKA874WRW0 Latch lever 1 AR
5- 8 LSTPPA181WRF0 Latch head 2 AL
5- 9 MSPRTA190WRE0 Latch spring 1 AD
5-10 PCUSUA506WRP0 Cushion 1 AC
5-11 XEPSD40P06000 Screw : 4mm x 6mm 1 AB
5-12 PSHEPA686WRE0 Panel sheet 2 AK
5-13 PSHEPA687WRE0 Panel sheet 1 AK

Sharp R-15AT Specifications

General

Grill	No
Rotisserie	-
Control type	Buttons
Display type	LCD
Product type	Solo microwave
Certification	CE
Product color	Stainless steel
Microwave power	1000 W
Built-in display	Yes
Appliance placement	Countertop
Number of power levels	11
Current	16 A
Connected load	- W
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	424 mm
Width	520 mm
Height	309 mm
Weight	18000 g
Interior dimensions (W x D x H)	351 x 372 x 211 mm
