21
R-1610
R-1611
R-1612
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
RY1-2 RRLY-A113DRE0 M Relay (DU24D1-1PR(M)) 2 AG
RY3-4 RRLY-B004MRE0 M Relay (FTR-F3AA024E) 2 AG
RY5 RRLY-A112DRE0 M Relay (VE24HSE-K) 1 AH
SSR1 RTR--A001DRE0 M Solid state relay 1 AG
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB017MRE0 M Transformer 1 BE
VRS1 RH-VZA032DRE0 J Varistor (10G471K) 1 AE
ZD1 VHEHZ161///-1 J Zener diode (HZ-161) 1 AA
3- 2 FPNLCB263MRK0 M Control panel sub. assembly [R-1610] 1
3- 2 FPNLCB264MRK0 M Control panel sub, assembly [R-1611] 1
3- 2 FPNLCB265MRK0 M Control panel sub, assembly [R-1612] 1
3- 2-1 FUNTKB213MRE0 M Key unit [R-1610] 1
3- 2-1 FUNTKB214MRE0 M Key unit [R-1611] 1
3- 2-1 FUNTKB215MRE0 M Key unit [R-1612] 1
3- 2-2 GMADIB033MRF0 M Display window [R-1611] 1 AK
3- 2-2 GMADIB033MRF0 M Display window [R-1612] 1 AK
3- 2-2 GMADIB034MRR0 M Display window [R-1610] 1 AK
3- 2-3 XEPSD30P10XS0 M Screw; 3mm x 10mm 1 AB
3- 3 LHLD-B011MRF0 M LCD holder 1 AD
3- 4 PSHEPB027MRE0 M LED sheet 1 AF
3- 5 XEPSD30P10XS0 M Screw; 3mm x 10mm 2 AB
OVEN PARTS
4- 1 FFTA-B003MRK0 M Exhaust damper assembly 1 AH
4- 2 FROLPB025MRK0 M Turntable support assembly 1 AN
4- 3 NTNT-A090WRE0 M Turntable tray 1 AN
4- 4 LANGKB010MRP0 M Capacitor holder 1 BB
4- 5 FCOVPB016MRK0 M Stirrer cover assembly 1 AN
4- 6 FFAN-B010MRK0 M Stirrer fan assembly 1 AH
4- 7 ************* M Oven cavity (Not replaceable part) 1 --
4- 8 PPACGB014MRF0 M Turntable motor packing 1 AA
4- 9 PHOK-B017MRF0 M Latch hook 1 AG
4-10 LANGTB036MRP0 M Unit mounting plate 1 AP
4-11 NFANPB001MRE0 M Fan blade 1 AC
4-12 LBSHC0037WRE0 M Cord bushing 1 AB
4-13 PCOVPB065MRP0 M Oven lamp cover 1 AD
4-14 PDUC-B095MRP0 M Hood intake duct R 1 AM
4-15 PCUSUB039MRP0 M Hood intake duct cushion 1 AA
4-16 PFILWB005MRP0 M Lamp filter 1 AB
4-17 LANGTB046MRP0 M Chassis support left 1 AD
4-18 LANGTB040MRP0 M Chassis support right 1 AE
4-19 PDUC-B094MRF0 M Hood duct 1 AL
4-20 LHLD-B012MRF0 M Rack holder 4 AF
4-21 LSTPPB031MRF0 M Door stopper 1 AC
4-22 PCOVPB076MRF0 M Louver cover A [R-1610] 1 AG
4-23 PCOVPB077MRF0 M Louver cover B [R-1610] 1 AG
4-24 PCOVPB078MRF0 M Louver cover C [R-1610] 1 AG
4-25 PDUC-B098MRP0 M Magnetron air guide 1 AC
DOOR PARTS
5- 1 FDORFB060MRT0 M Door panel assembly 1 AX
5- 2 FCOV-B146MRK0 M Door frame assembly [R-1610] 1 BD
5- 2 FCOV-B145MRK0 M Door frame assembly [R-1611] 1 BD
5- 2 FCOV-B147MRK0 M Door frame assembly [R-1612] 1 BC
5-2-1 PGLSPB012MRE0 M Front door glass [R-1610] 1 AQ
5-2-1 PGLSPB014MRR0 M Front door glass [R-1611] 1 AQ
5-2-1 PGLSPB013MRR0 M Front door glass [R-1612] 1 AQ
5-2-2 LSTPPB030MRF0 M Latch head 1 AC
5-2-3 LSTPPB032MRF0 M Glass stopper 1 AC
5-2-4 MSPRTA046WRE0 M Latch spring 1 AB
5-2-5 GWAKPB105MRR0 M Door frame [R-1610] 1 AZ
5-2-5 GWAKPB104MRR0 M Door frame [R-1611] 1 AZ
5-2-5 GWAKPB106MRR0 M Door frame [R-1612] 1 AV
5- 3 FCOVHB005MRK0 M Choke cover assembly 1 AH
5- 4 PSHEPB024MRE0 M Sealer film 1 AF
5- 5 FHNDPB002MRK0 M Door handle assembly [R-1610] 1 AL
5- 5 FHNDPB001MRK0 M Door handle assembly [R-1611] 1 AL
5- 5 FHNDPB003MRK0 M Door handle assembly [R-1612] 1 AL
5- 6 XCPSD40P08000 M Screw : 4mm x 8mm 4 AA
5- 7 XCPSD40P12000 M Screw : 4mm x 12mm 2 AA
∆
∆
∆
∆
∆
∆
∆
∆
∆
∆
∆
∆
∆
