Sharp R-1612 - Parts List

20
R-1610
R-1611
R-1612
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION
ELECTRIC PARTS
1- 1 FH-DZB012MRY0 M High voltage rectifier assembly 1 AK
1- 2 RC-QZA234WRE0 M High voltage capacitor 1 AP
1- 3 QFS-TA013WRE0 M Temperature fuse 150˚C (Magnetron) 1 AG
1- 4 RMOTDA211WRE0 M Turntable motor 1 AL
1- 5 RMOTDA214WRE0 M Stirrer motor 1 AQ
1- 6 RTHM-B005MRE0 M Thermal cut-out N.O. 60˚C (Hood Fan) 1 AG
1- 7 RTRN-B062MRE0 M Power transformer 1 BF
1- 8 RV-MZA281WRE0 M Magnetron 1 BC
1- 9 QFSHDB003MRE0 M Fuse holder 1 AD
1-10 QSW-MA110WRE0 M Secondary interlock and door sensing switches 2 AE
1-11 FFS-BA016/KIT M Monitor switch with fuse assembly 1 AF
1-12 FACCDB011MRE0 M Power supply cord 1 AP
1-13 QSOCLB006MRE0 M Oven lamp socket 3 AE
1-14 FMOTEA366WRK0 M Hood fan motor 1 BE
1-15 RMOTEA346WRE0 M Fan motor 1 AR
1-16 RLMPTA068WRE0 M Oven lamp 3 AE
1-17 RTHM-A070WRE0 M Thermal cut-out 145˚C (Cavity) 1 AG
1-18 FDTCTA201WRK0 M AH sensor 1
CABINET PARTS
2- 1 LSTY-B021MRP0 M Rear stay 1 AF
2- 2 PDIF-B018MRF0 M Hood exhaust louver [R-1610] 1 AT
2- 2 PDIF-B019MRF0 M Hood exhaust louver [R-1611] 1 AT
2- 2 PDIF-B020MRF0 M Hood exhaust louver [R-1612] 1 AT
2- 3 GDAI-B055MRP0 M Right base plate 1 AM
2- 4 PCUSUB040MRP0 M Base cover cushion 1 AA
2- 5 GCABUB084MRP0 M Outer case cabinet [R-1610] 1 BA
2- 5 GCABUB090MRP0 M Outer case cabinet [R-1611] 1 BC
2- 5 GCABUB086MRP0 M Outer case cabinet [R-1612] 1 BC
2- 6 TMAPCB052MRR0 M Schematic diagram 1 AB
2- 7 FANGKB009MRY0 M Hood lamp glass assembly [R-1610] 1 AN
2- 7 FANGKB010MRY0 M Hood lamp glass assembly [R-1611] 1 AM
2- 7 FANGKB011MRY0 M Hood lamp glass assembly [R-1612] 1 AM
2-7-1 LANGQB016MRP0 M Hood lamp glass angle [R-1610] 1 AG
2-7-1 LANGQB020MRP0 M Hood lamp glass angle [R-1611] 1 AG
2-7-1 LANGQB027MRP0 M Hood lamp glass angle [R-1612] 1 AG
2-7-2 PGLSPB004MRE0 M Hood lamp glass 1 AH
2- 8 PCOVPB064MRT0 M Base cover [R-1610] 1 AY
2- 8 PCOVPB066MRT0 M Base cover [R-1611] 1 AY
2- 8 PCOVPB067MRT0 M Base cover [R-1612] 1 AY
CONTROL PANEL PARTS
3- 1 CPWBFB037MRU0 M Control unit 1
3- 1A QCNCMA447DRE0 M 4-pin connector CN-A 1 AA
3- 1B QCNCMA448DRE0 M 5-pin connector CN-B 1 AA
3- 1C QCNCMA275DRE0 J 2-pin connector CN-E 1 AB
3- 1D FW-VZA253DRE0 M Lead wire harness CN-C 1 AU
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
C3 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C4-5 VCEAB31VW106M J Capacitor 10 uF 35V 2 AB
C100 RC-QZB014MRE0 M Capacitor 7 uF 230V 1 AK
C110 RC-QZB019MRE0 M Capacitor 0.033 uF 250V 1 AC
D1-4 VHD11ES1///-1 J Diode (11ES1) 4 AB
D5-6 VHD1SS270A/-1 J Diode (1SS270A) 2 AA
D21-25 VHD1SS270A/-1 J Diode (1SS270A) 5 AA
Q1-2 VS2SB1238//-3 J Transistor (2SB1238) 2 AA
Q3 VSKRC243M//-3 J Transistor (KRC243M) 1 AB
R1 VRD-B12EF242J J Resistor 2.4k ohm 1/4W 1 AA
R2 VRD-B12HF681J J Resistor 680 ohm 1/2W 1 AA
R3 VRD-B12HF511J J Resistor 510 ohm 1/2W 1 AB
R4 VRD-B12EF270J J Resistor 27 ohm 1/4W 1 AB
R5 VRD-B12EF472J J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
R20 VRD-B12HF102J J Resistor 1k ohm 1/2W 1 AA
R110 VRS-A12HA470J J Resistor 47 ohm 1/2W 1 AH
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
*
*
*
∆
*
