[1] OVEN PARTS
ELECTRIC PARTS
1-1 FFS-BA033WRKZ -- Monitor fuse20A and monitor switch (V-5220Q)
1-2 QSW-MA085WRE0 AF Door sensing switch
1-3 QSW-MA135WRE0 AH Secondary interlock switch
1-4 FACCDA116WREZ AV Power supply cord
!
1-5 FH-DZA119WRKZ AU High voltage rectifier assembly
!
1-6 RC-QZA235WRE0 AU High voltage capacitor
!
1-6 RC-QZA336WRZZ -- High voltage capacitor for production use (Interchangeable)
1-7 RMOTEA376WRE0 AU Fan motor
1-8 FPWBFA389WRKZ AW Noise filter
1-8 FPWBFA417WRKZ AY Noise filter (Interchangeable)
1-9 QSOCLA021WRE0 AG Oven lamp socket
1-10 RLMPTA086WRZZ AL Oven lamp
1-11 RMOTDA233WRE0 AQ Antenna motor
1-12 RTHM-A138WRZZ AH Thermal cut-out 145 deg. (MAG)
1-12 RTHM-A080WRE0 AP Thermal cut-out 145 deg. (MAG) (Interchangeable)
1-12 RTHM-A120WRE0 AH Thermal cut-out 145 deg. (MAG) (Interchangeable)
1-13 RTHM-A137WRZZ AH Thermal cut-out 125 deg. (OVEN)
1-13 RTHM-A096WRE0 AK Thermal cut-out 125 deg. (OVEN) (Interchangeable)
1-13 RTHM-A123WRZZ AK Thermal cut-out 123 deg. (OVEN) (Interchangeable)
!
1-14 RTRN-A751WRZZ BP Power transformer
!
*
1-15 RV-MZA347WRZZ BH Magnetron
CABINET PARTS
2-1 GCABUA674WRP0 AX Outer case cabinet
2-2 GDAI-A311WRW0 AS Base plate
2-3 GCOVHA406WRW0 AQ Base plate cover
2-4 GLEGPA074WRE0 AC Foot
2-5 GLEGPA076WRF0 AF Leg
OVENPARTS
4-1 FGLSPA062WRE0 BL Ceramic shelf
* 4-2 ************* -- Oven cavity (Not a replaceable part)
4-3 MLEVPA227WRF0 AF Latch switch lever A
4-4 MLEVPA228WRF0 AF Latch switch lever B
4-5 MLEVPA229WRF0 AF Latch switch lever C
4-6 MSPRCA108WRE0 AC Latch lever spring
4-7 MSPRTA191WRE0 AC Switch lever B spring
* 4-8 PHOK-A160WRFZ AN Latch hook
4-9 FDUC-A341WRY0 BL Steam duct sub assembly
4-10 PSKR-A351WRP0 AY Steam guide
4-11 LBNDKA136WRP0 AQ HV capacitor holder
4-12 NFANJA029WRE0 AK Fan blade
4-13 PDUC-A888WRFZ AM Fan duct
4-14 FPLT-A007WRY0 BB Stirrer antenna assembly
4-15 PCUSGA504WRP0 AB Insertion cushion
4-16 PSKR-A348WRW0 AN Insertion plate A
4-17 GCOVHA509WREZ AG VCP cap
4-18 LANGFA199WRWZ AH Chassis support
4-19 NSFTPA035WRFZ AQ Antenna motor shaft
4-20 PCLICA032WRE0 AD Hand clip 4
4-21 PCLICA033WRE0 AD Hand clip 5
4-22 PCOVPA344WRF0 AF Side splash cover
4-23 PCOVPA345WRF0 AF Back splash cover
4-24 PCUSGA249WRP0 AA Cushion
4-25 PCUSUA511WRP0 AC Cushion
4-26 PCUSUA194WRP0 AC Cushion
4-27 PCUSUA514WRP0 AB Cushion
4-28 PDUC-A966WRFZ AT Air intake duct
4-29 PFILWA060WRP0 AD Lamp filter
4-30 PSHEPA644WRE0 AD Insertion sheet
4-31 PSKR-A347WRW0 AL Insertion plate B
4-32 PSKR-A349WRP0 AF Steam duct barrier
4-33 PSKR-A359WRW0 AM Air guide
4-34 PSPA-A112WRE0 AC Mica washer
4-35 PCUSGA378WRP0 AL Cushion
4-36 PCUSUA507WRP0 AC Cushion
4-37 PCUSUA517WRP0 AE Cushion
4-38 PSHEPA674WRE0 AL Cover
4-39 PCUSUA518WRP0 AC Cushion
4-40 PSHEPA673WRE0 AD S/Film
MISCELLANEOUS
6-1 TMAPCA779WRRZ AH Schematic diagram
6-2 TCAUAA249WRR0 AE Caution label
6-3 TCAUAA250WRR0 AF DHHS caution label
6-4 TCAUAA295WRRZ AH Monitor caution
6-5 TCAUAA243WRR0 AC Earth caution
6-6 TCAUAA245WRR0 AC Cover caution
SCREWS, NUTS AND WASHERS
7-1 XHPS740P08K00 AB Screw : 4mm x 8mm
7-2 XEPS740P25000 AB Screw : 4mm x 25mm
7-3 LX-CZA038WRE0 AA Special screw
7-4 LX-CZ0052WRE0 AA Special screw
7-5 LX-EZA042WRE0 AB Special screw
7-6 XBPWW40P04000 AB Screw : 4mm x 4mm
