Sharp R-21LCF - Page 38

R21LCF
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[2] DOOR AND CONTROL PANEL PARTS
CONTROL PANEL PARTS
3-1 DPWB-A416DRKZ BG Control unit
3-2 FPNLCB911WRKZ BB Panel sub assembly
3-2-1 HPNLTA200WREZ AN Timer sheet
3-2-2 GCOVAA260WRP0 BA C/P case
3-3 TCAUAA076WRR0 AB User caution label
3-4 JKNBKA606WRM0 AL Timer knob
3-5 XEPS730P08XS0 AA Screw; 3mm x 8mm
3-6 PRNGFA001WRF0 AC Ring
DOOR PARTS
* 5-1 CDORFB052WRKZ BT Door assembly
* 5-1-1 FDORFA322WRT0 AZ Door panel assembly
5-1-2 PSHEPA649WRE0 AB Sealer film
* 5-1-3 FANGKA206WRY0 AW Latch angle assembly
* 5-1-4 FCOV-A012WRKZ BQ Door case assembly
5-1-4-1 LSTPPA180WRF0 AK Glass stopper R
5-1-4-2 LSTPPA182WRF0 AN Glass stopper U
5-1-4-3 PGLSPA516WRE0 AU Front door glass
5-1-4-4 PSLDMA198WREZ BB Sealer plate
5-1-4-5 XETS740P08000 AA Screw : 4mm x 8mm
5-1-5 GWAKPA580WRM0 AQ Door handle
5-1-6 JHNDMA040WRW0 AN Handle lever
* 5-1-7 LANGKA874WRW0 AR Latch lever
* 5-1-8 LSTPPA181WRF0 AL Latch head
5-1-9 MSPRTA190WRE0 AD Latch spring
5-1-10 PCUSUA506WRP0 AC Cushion
5-1-11 XEPS740P06000 AA Screw : 4mm x 6mm
5-1-12 PSHEPA686WRE0 AK Panel sheet
5-1-13 PSHEPA687WRE0 AK Panel sheet
5-1-14 PCUSGA514WRP0 AK Cushion
5-1-15 PCUSUA505WRP0 AC Cushion
5-1-16 XEBS738P08000 AB Screw : 3.8mm x 8mm
5-1-17 XEPS740P25K00 AC Screw : 4mm x 25mm
5-1-18 PCUSUA508WRP0 AC Cushion
* 5-2 GCOVHA407WRF0 AM Choke cover
5-3 HBDGCA123WREZ AK Door badge
* 5-4 PPACGA171WRE0 AK Cushion (ferrite)
MISCELLANEOUS
6-7 TINSEB126WRRZ AM Instruction book
6-8 FW-VZC073WREZ AX Main wire harness
6-9 LHLDWA013WRE0 AC Purse lock LL
