Sharp R-22AM Service Manual

30
R-22AM
R-23AM
R-23AT
Table of EEPROM data
Memory Data Contents
Pad
3 2 2 3 5 Higher temperature limit setting of
magnetron thermistor detection
4 0 0 0 0 Constant setting of fan lock detection
6 0 1 0 0 Time setting of fan lock detection
8 3 2 0 0 Higher temperature limit setting of
exhaust air detection
9 0 0 0 0 Constant setting of fan lock detection
11 0 0 0 0 Constant setting of magnetron
thermistor detection
12 0 0 0 0 Constant setting of magnetron
thermistor detection
13 0 0 0 0 Constant setting of magnetron
thermistor detection
14 0 0 0 0 Constant setting of magnetron
thermistor detection
15 1 5 Interval time setting of magnetron
thermistor detection
20 0 0 0 0 Switch level setting of magnetron
thermistor detection
OTHER CHECKING AND CLEARING PROCE-
DURE FOR R-23AT
1) To check the contents of defrost.
" " : Flicker / : 0.1 sec BUZZER
PAD ORDER DISPLAY PHONE
(Door close) •
CHECK "NUMBER" • CHECK
DEFROST 1 0.20 DEF CHECK
(A)
DEF CHECK
1 20 POWER
(+ - B) 50%
2 0.13 DEF CHECK
(A)
DEF CHECK
2 30 POWER
(+ - B) 30%
DEF CHECK
3 5 POWER
20%
(Repeat)
CHECK •
#1: No key entry signal.
2) How to clear all counter(user and service) and total
cooking time and used time of filter.
PAD ORDER DISPLAY PHONE
(Door close) •
SET •
SET "NUMBER" •
DOUBLE "NUMBER" • DOUBLE
CHECK "NUMBER" • DOUBLE
VOLUME "NUMBER" • DOUBLE
SET •
2) How to enter the memory information
Example : Suppose cooking time 5 sec. and output power
100% are entered into the memory pad 1.
PAD ORDER DISPLAY PHONE
(Door close) •
SET •
SET "NUMBER" •
(within 2 sec.)
1 NUMBER 1 • 0
5 NUMBER 1 • 5
SET "NUMBER" •
SET •
Enter the memory information into the memory pads 1 ~ 10
referring to above example. The memory information are
given below.
Memory No. Cook Time Output Power
1 5 sec. 100%
2 10 sec. 100%
3 20 sec. 100%
4 30 sec. 100%
5 40 sec. 100%
6 50 sec. 100%
7 1 min. 100%
8 1 min.15 sec. 100%
9 1 min.30 sec. 100%
10 2 mins. 100%
11-20 0 sec.
3) How to enter the EEPROM data
Enter the EEPROM data into the memory pads, 3, 4, 6, 8,
9, 11, 12, 13, 14, 15 and 20, referring to following example
and the table of EEPROM data.
Example : Suppose the EEPROM data "2235" is entered
into the memory pad 3.
" " : Flicker / : 0.1 sec BUZZER
PAD ORDER DISPLAY PHONE
(Door close) •
CHECK "NUMBER" • CHECK
CHECK #2 82 68 "CHECK"
(User's Total Counts)
#1 VOLUME #2 82 68 "CHECK"
VOLUME #2 82 68 "CHECK"
DOUBLE #3 XXXXXX "CHECK"
QUANTITY
(Total Counts of Service)
3 30 30 "CHECK"
SET 0 "CHECK"
2,2,3,5 22 35 "CHECK" x 4
SET 22 35 "CHECK"
CHECK •
#1: Denotes the procedure for the servicer to disable
clearing. This procedure is instructed to service per-
sonnel only and is excluded from the operation manual.
#2: If IC-2 is exchanged, 0 should be indicated instead of
8268. But if the control unit is exchanged, 0 is not
always indicated.
#3: Total counts of service, 6 figures will be displayed.
