5
R-22AM
R-23AM
R-23AT
GENERAL INFORMATION
WARNING
THIS APPLIANCE MUST BE EARTHED
IMPORTANT
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
GREEN-AND-YELLOW : EARTH
BLUE : NEUTRAL
BROWN : LIVE
PRODUCT DESCRIPTION
SPECIFICATION
ITEM DESCRIPTION
Power Requirements 230 Volts
50 Hertz
Single phase, 3 wire earthed
Power Comsumption
2.4 kW Approx. 11 A [R-22AM] / 2.9 kW Approx. 13 A [R-23AM, R-23AT]
Power Output
1500 W [R-22AM]/ 1800 W [R-23AM/23AT] nominal of RF microwave energy
(measured by method of IEC 60705)
Operating frequency 2450 MHz
Case Dimensions Width Height Depth
510mm 335 mm 470mm
Cooking Cavity Dimensions Width Height Depth
330 mm 180 mm 330mm
Control Complement for R-23AT Touch Control System
The combination of cooking time and microwave power
The oven can be programmed a series of up to 3 cookling stages.
The combination of microwave power and cooking time that can be input as
folllows.
Cooking Sequence Micrwave power levelthat can be iused. Cooking time that can be iused.
1 Stage only 0-100% Max. 30 minutes
0-40% all stages Max. 30 minutes any stages
Max. 60 minutes for 2 stages
2 or 3 Stage
Max. 90 minutes for 3 stages
50-100% Max. 30 minutes for 3 stages
NOTE:If the oven used with the power level above 40% on any stage, the
maximum cooking time is 30 minutes in total.
Microwave Power level
100% 90% 80% 70% 60% 50% 40% 30% 20% 10% 0%
MANUAL / REPEAT key, NUMBER keys
POWER LEVEL key, STOP / CLEAR key
START Key, DOUBLE QUANTITY key
DEFROST key, SET key
CHECK key, VOLUME key
Control Complement for R-22AM/23AM
Electronic Timer (0 - 30 minutes)
Microwave Power level
100% 50% 20% 10%
MICROWAVE POWER SETTING buttons
START button
Set Weight Approx. 33 kg
