45
R-22AT
R-23AM
R-24AT
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
4-33 LBSHCA012WRE0 Cord bushing 1 AD
4-34 PCOVPA351WRF0 Stirrer cover 1 BA
4-35 FFIL-A005WRK0 Air intake filter assembly 1 AS
4-36 HDECEA001WRP0 Decoration sash 1 AR
4-37 HDECQA146WRM0 Corner cap left 1 AE
4-38 PCUSGA409WRP0 Cushion 2 AE
4-39 LANGQA440WRM0 Earth angle 1 AE
4-40 LANGQA512WRP0 Thermistor angle 1 AE
4-41 PCUSUA458WRP0 Cushion 1 AB
4-42 LANGQA514WRW0 Noise filter angle 1 AF
4-43 PCUSUA268WRP0 Cushion 1 AA
4-44 MSPRCA101WRE0 Switch lever spring C 1 AC
DOOR PARTS
5 DDORFA746WRK0 Door assembly 1 BP
5- 1 FDORFA289WRT0 Door panel assembly 1 BH
5- 2 GCOVAA242WRY0 Door case 1 BD
5- 3 FHNDMA011WRY0 Door lever assembly 1 AP
5- 4 GCOVHA350WRF0 Choke cover 1 AR
5- 5 JHNDPA169WRM0 Door handle 1 AU
5- 6 LANGKA766WRP0 Outside window fixing plate 2 AF
5- 7 PCUSGA430WRP0 Cushion 2 AM
5- 8 PGLSPA457WRE0 Door glass 1 AV
5- 9 PPACGA142WRP0 Door case packing 2 AF
5-10 PSHEPA428WRE0 Sealer film 1 AF
5-11 XWSSD40-10000 Washer : 4mm x 1mm 2 AA
5-12 XFPSD40P08K00 Screw : 4mm x 8mm 3 AA
5-13 XHTSD40P08RV0 Screw : 4mm x 8mm 4 AA
5-14 FANGKA200WRY0 Latch fixing angle 1 AQ
5-15 FLEVFA019WRY0 Joint lever 1 AP
5-16 LSTPCA002WRM0 Latch head 2 AM
5-17 MLEVPA220WRF0 Head lever 1 AM
5-18 MSPRCA097WRE0 Latch spring 1 AG
5-19 HBDGCA091WRE0 Door badge [R-24AT] 1 AF
5-19 HBDGCA092WRE0 Door badge [R-23AM] 1 AF
5-19 HBDGCA094WRE0 Door badge [R-22AT] 1 AF
5-20 XEPSD40P20000 Screw : 4mm x 20mm 2 AB
5-21 PCUSUA523WRP0 Door lever cushion 2 AE
5-22 PSPA-A102WRE0 Door case spacer 2 AE
MISCELLANEOUS
6- 1 TINSEA821WRR0 Operation manual [R-22AT, R-24AT] 1 AG
6- 1 TINSEA822WRR0 Operation manual [R-23AM] 1 AG
6- 2 TLABHA029WRR0 Menu sticker [R-22AT, R-24AT] 1 AC
6- 3 FW-VZB769WRE0 Switch harness 1 AR
6- 4 FW-VZB765WRE0 Main wire harness 1 BB
6- 5 TLAB-A186WRR0 AL label 1 AB
6- 6 LBNDKA079WRE0 Wire holder 3 AB
6- 7 PTUB-A048WRZZ Tube 1 AF
6- 8 TCAUH0057YBR0 Lamp caution 1 AD
6- 9 TSPCNC828WRR0 Rating label [R-24AT] 1 AH
6- 9 TSPCNC830WRR0 Rating label [R-23AM] 1 AH
6- 9 TSPCNC832WRR0 Rating label [R-22AT] 1 AH
6-10 TCAUAA205WRR0 Cord caution 1 AE
6-11 TCAUH0114WRR0 Caution label 1 AC
6-12 TCAUHA257WRR0 S caution sheet 1 AE
6-13 LHOLDA004WRE0 Cord holder 1 AA
6-14 PZET-A018WRE0 Terminal insulator 2 AC
6-15 TLABSA065WRR0 BS 13 label 1 AC
6-16 LHLDWQ004YBE0 Purse lock L 1 AA
6-17 TLABSA069WRR0 Fuse label F6.3A 1 AB
6-18 TLABSA070WRR0 Fuse label M8A 2 AB
6-19 TLABSA066WRR0 Equipotential label 1 AD
SCRE,NUTS AND WASHERS
7- 1 XCBWW30P08000 Screw : 3mm x 8mm 2 AB
7- 2 XBPSD30P28KS0 Screw : 3mm x 28mm 1 AA
7- 3 XNESD30-24000 Nut : 3mm x 2.4mm 1 AA
7- 4 LX-BZA130WRE0 Special screw 1 AD
7- 5 LX-BZA116WRE0 Special screw 2 AD
7- 6 XBPWW40P04000 Screw : 4mm x 4mm 4 AB
7- 7 LX-BZA041WRE0 Special screw 2 AA
7- 8 LX-BZA125WRE0 Special screw 2 AB
7- 9 LX-CZA038WRE0 Special screw 2 AA
7-10 LX-EZA004WRE0 Special screw 2 AA
7-11 XOTSD40P06000 Screw : 4mm x 6mm 2 AA
