49
R-22AT
R-23AM
R-24AT
REF. NO. PART NO. DESCRIPTION Q'TY CODE
3- 1 DPWBFB998WRU0 Control unit [R-24AT] 1 BN
3- 1 DPWBFC005WRU0 Control unit [R-22AT] 1 BN
3- 1A QCNCMA308DRE0 4-pin connector (A) 1 AC
3- 1B QCNCMA312DRE0 3-pin connector (B) 1 AB
3- 1C QCNCWA030DRE0 12-pin connector (G) 1 AF
3- 1D QCNCMA039DRE0 3-pin connector (H) 1 AB
3- 1E QLUG-A002PRE0 Tab terminal (TAB1-4) 4 AB
3- 1F RV-KXA053DRE0 Fluorescent display tube 1 AW
3- 1G PCUSGA359WRP0 Cushion 2 AC
C1 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C2 RC-EZA192DRE0 Capacitor 1000 uF 35V 1 AD
C3 VCEAB31HW335M Capacitor 3.3 uF 50V 1 AA
C4 VCKYB11EX103N Capacitor 0.01 uF 25V 1 AA
C5 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C6-7 VCKYD11CY103N Capacitor 0.01 uF 16V 2 AA
C8 VCEAB31CW107M Capacitor 100 uF 16V 1 AB
C9 VCEAB31EW226M Capacitor 22 uF 25V 1 AA
C20 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C21 VCKYF31HF103Z Capacitor 0.01 uF 50V 1 AA
C22 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C30 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C61-62 VCEAB31EW226M Capacitor 22 uF 25V 2 AA
C70 VCKYF31HF103Z Capacitor 0.01 uF 50V 1 AA
C71 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C72 VCKYB11EX103N Capacitor 0.01 uF 25V 1 AA
C74 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C80 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AM
C81 VCEAB31HW225M Capacitor 2.2 uF 50V 1 AA
C82 VCEAB31HW105M Capacitor 1.0 uF 50V 1 AA
C200 VRD-B12EF183J Resistor 18k ohm 1/4W 1 AA
CF1 RCRS-A010DRE0 Ceramic resonator (CST4.00MGW) 1 AD
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D6-7 VHD11ES1///-1 Diode (11ES1) 2 AB
D61-64 VHD1SS270A/-1 Diode (1SS270A) 4 AA
D70 VHD11ES1///-1 Diode (11ES1) 1 AB
D71 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D81 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D83-84 VHD1SS270A/-1 Diode (1SS270A) 2 AA
D93-97 VHD1SS270A/-1 Diode (1SS270A) 5 AA
IC1 RH-IZA646DRE0 LSI 1 AX
IC2 RH-IZA571DRE0 IC (AT24C04) 1 AP
Q1 VS2SB953-PQ-4 Transistor (2SB953) 1 AG
Q2 VS2SA933AS/-3 Transistor (2SA933ASTP) 1 AB
Q20 RH-TZA037CBE0 Transistor (KRA101M) 1 AA
Q40 RH-TZA037CBE0 Transistor (KRA101M) 1 AA
Q41 VS2SB1238//-3 Transistor (2SB1238) 1 AA
Q80 VSDTA114YSA-3 Transistor (DTA114YSA) 1 AB
Q81 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
Q83-84 VSDTB143ES/-3 Transistor (DTB143ES) 2 AC
R1 VRD-B12EF182J Resistor 1.8k ohm 1/4W 1 AA
R3 VRD-B12HF561J Resistor 560 ohm 1/2W 1 AA
R4 VRD-B12EF102J Resistor 1.0k ohm 1/4W 1 AA
R5 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R6 VRD-B12HF150J Resistor 15 ohm 1/2W 1 AA
R20 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R31 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R32 VRD-B12EF272J Resistor 2.7k ohm 1/4W 1 AA
R33 VRD-B12EF103J Resistor 10k ohm 1/4W 1 AA
R40 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R41 VRD-B12EF203J Resistor 20k ohm 1/4W 1 AA
R42 VRD-B12EF393J Resistor 39k ohm 1/4W 1 AA
R43 VRD-B12EF103J Resistor 10k ohm 1/4W 1 AA
R50 VRD-B12EF182J Resistor 1.8k ohm 1/4W [R-24AT] 1 AA
R50 VRD-B12EF202J Resistor 2.0k ohm 1/4W [R-22AT] 1 AA
R61-62 VRN-B12EK202F Resistor 2.0k ohm(F) 1/4W 2 AA
R63-64 VRD-B12EF102J Resistor 1.0k ohm 1/4W 2 AA
R65-66 VRD-B12EF304J Resistor 300k ohm 1/4W 2 AA
R67-68 VRD-B12EF473J Resistor 47k ohm 1/4W 2 AA
R70 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R71 VRD-B12EF303J Resistor 30k ohm 1/4W 1 AA
R72 VRD-B12EF112J Resistor 1.1k ohm 1/4W 1 AA
R73 VRD-B12EF333J Resistor 33k ohm 1/4W 1 AA
R74 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R79 VRD-B12EF473J Resistor 47k ohm 1/4W 1 AA
R80 VRD-B12EF471J Resistor 470 ohm 1/4W 1 AA
R93-101 VRD-B12EF153J Resistor 15k ohm 1/4W 9 AA
CONTROL PANEL PARTS FOR R-24AT / R-22AT
