R-22AT
R-23AM
R-24AT
3- 1 DPWBFC003WRU0 Control unit 1 BL
3- 1A QCNCMA308DRE0 4-pin connector (A) 1 AC
3- 1B QCNCMA312DRE0 3-pin connector (B) 1 AB
3- 1C QCNCMA381DRE0 5-pin connector (E) 1 AD
3- 1D QCNCMA039DRE0 3-pin connector (H) 1 AB
3- 1E QCNCMA338DRE0 3-pin connector (J) 1 AB
3- 1F QLUG-A002PRE0 Tab terminal (TAB1-4) 4 AB
3- 1G RV-KXA053DRE0 Fluorescent display tube 1 AW
3- 1H PCUSGA400WRP0 Cushion 2 AC
C1 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C2 RC-EZA192DRE0 Capacitor 1000 uF 35V 1 AD
C3 VCEAB31HW335M Capacitor 3.3 uF 50V 1 AA
C4 VCKYB11EX103N Capacitor 0.01 uF 25V 1 AA
C5 VCEAB31CW476M Capacitor 47 uF 16V 1 AA
C6-7 VCKYD11CY103N Capacitor 0.01 uF 16V 2 AA
C8 VCEAB31CW107M Capacitor 100 uF 16V 1 AB
C9 VCEAB31EW226M Capacitor 22 uF 25V 1 AA
C10 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C11 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C12 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C20 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AM
C21 VCEAB31VW475M Capacitor 4.7 uF 35V 1 AA
C30-31 VCEAB31EW226M Capacitor 22 uF 25V 2 AA
C50 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C60 VCKYB11EX103N Capacitor 0.01 uF 25V 1 AA
C80-81 RC-KZA129DRE0 Capacitor 2200 pF 16V 2 AB
C90 VRD-B12EF183J Resistor 18k ohm 1/4W 1 AA
CF1 RCRS-A010DRE0 Ceramic resonator CST4.00MGW 1 AD
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D6-7 VHD11ES1///-1 Diode (11ES1) 2 AB
D20 VHD11ES1///-1 Diode (11ES1) 1 AB
D21-23 VHD1SS270A/-1 Diode (1SS270A) 3 AA
D30-33 VHD1SS270A/-1 Diode (1SS270A) 4 AA
D50 VHD1SS270A/-1 Diode (1SS270A) 1 AA
IC1 RH-IZA648DRE0 LSI 1 AV
Q1 VS2SB953-PQ-4 Transistor (2SB953) 1 AG
Q2 VS2SA933AS/-3 Transistor (2SA933ASTP) 1 AB
Q10 RH-TZA037CBE0 Transistor (KRA101M) 1 AA
Q20 VSDTA114YSA-3 Transistor (DTA114YSA) 1 AB
Q21 VSDTD143ES/-3 Transistor (DTD143ES) 1 AC
Q22-23 VSDTB143ES/-3 Transistor (DTB143ES) 2 AC
Q70 RH-TZA037CBE0 Transistor (KRA101M) 1 AA
R1 VRD-B12EF182J Resistor 1.8k ohm 1/4W 1 AA
R2 VRD-B12HF561J Resistor 560 ohm 1/2W 1 AA
R3 VRD-B12EF102J Resistor 1.0k ohm 1/4W 1 AA
R4 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R5 VRD-B12HF150J Resistor 15 ohm 1/2W 1 AA
R10 VRD-B12EF153J Resistor 15k ohm 1/4W 1 AA
R20 VRD-B12EF471J Resistor 470 ohm 1/4W 1 AA
R30-31 VRD-B12EF202J Resistor 2.0k ohm 1/4W 2 AA
R32-33 VRD-B12EF102J Resistor 1.0k ohm 1/4W 2 AA
R34-35 VRD-B12EF304J Resistor 300k ohm 1/4W 2 AA
R36-37 VRD-B12EF473J Resistor 47k ohm 1/4W 2 AA
R40 VRD-B12EF112J Resistor 1.1k ohm 1/4W 1 AA
R41 VRD-B12EF114J Resistor 110k ohm 1/4W 1 AA
R42 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R50 VRD-B12EF101J Resistor 100 ohm 1/4W 1 AA
R51 VRD-B12EF512J Resistor 5.1k ohm 1/4W 1 AA
R63 VRD-B12EF473J Resistor 47k ohm 1/4W 1 AA
R65 VRD-B12EF182J Resistor 1.8k ohm 1/4W 1 AA
R70 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
R80-81 VRD-B12EF224J Resistor 220k ohm 1/4W 2 AA
R82-83 VRD-B12EF472J Resistor 4.7k ohm 1/4W 2 AA
R84-85 VRD-B12EF153J Resistor 15k ohm 1/4W 2 AA
R90 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R91 VRD-B12EF682J Resistor 6.8k ohm 1/4W 1 AA
(5) VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
RY1 RRLY-A078DRE0 Relay (OJ-SH-118LM) 1 AG
RY2-3 RRLY-A087DRE0 Relay (VS18MB) 2 AN
SP1 RALM-A007DRE0 Buzzer (PKM22EPT-CA) 1 AF
T1 RTRNPA081DRE0 Touch control transformer 1 AU
CT1-2 RTRN-A060DRE0 Current transformer 2 AH
VRS1 RH-VZA034DRE0 Varistor (10G471K) 1 AD
ZD1 VHEHZ12C1//-1 Zener diode (HZ12C1) 1 AA
ZD2 VHEHZ4C3///-1 Zener diode (HZ4C3) 1 AA
3- 2 FPNLCB471WRK0 Control panel frame assembly 1 AX
REF. NO. PART NO. DESCRIPTION Q'TY CODE
CONTROL PANEL PARTS FOR R-23AM
