Sharp R-22GT-F User Manual

R-22GT-F
R-22GV-F
41
∆
*
*
*
*
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 FPWBFA383WRKZ Noise filter 1 AN
1- 2 QSOCLA026WRZZ Oven lamp socket 1 AF
1- 3 RV-MZA335WRZZ Magnetron 2 BA
1- 4 FMOTEA495WRKZ Blower motor 1 BF
1- 5 RTRN-A724WRZZ Power transformer 2 BF
1- 6 FACCDA112WRKZ Power supply cord 1 BB
1- 7 FH-HZA070WRE0 Oven thermistor (1) & Magnetron thermistor 2 AM
1- 8 FW-QZA117WRK0 High voltage rectifier assembly 1 AU
1- 9 FFS-BA033WRKZ Monitor switch (V-5220Q) and fuse 20A assembly 2 **
1-10 QFS-TA015WRE0 Temperature fuse 120C (OVEN) 1 AG
1-11 QSW-MA085WRE0 Secondary interlok switch and Door sensing switch 3 AF
1-12 RC-QZA325WRZZ High voltage capacitor 2 AP
1-13 RLMPTA081WRZZ Oven lamp 1 AK
1-14 RMOTDA209WRE0 Stirrer motor 2 AR
1-15 QFS-TA014WRE0 Temperature fuse 150C (MG.) 2 AG
CABINET PARTS
2- 1 FDAI-A275WRTZ Base plate assembly 1 BC
2- 2 PSHEGA009WREZ Rubber sheet D 2 AF
2- 3 PSHEGA010WREZ Rubber sheet E 2 AE
2- 4 GCOVAA283WRW0 Rear cabinet 1 AX
2- 5 FFTASA072WRY0 Oven lamp access cover assembly [R-22GV-F] 1 AM
2- 5 FFTASA064WRY0 Oven lamp access cover assembly [R-22GT-F] 1 AN
2- 5-1 PCUSU0407WRP0 Cushion [R-22GV-F] 1 AA
2- 5-1 PCUSUA585WRPZ Cushion [R-22GT-F] 1 AF
2- 5-2 PREFHA059WRP0 Reflector [R-22GT-F only] 1 AF
2- 6 GCABUA531WRP0 Outer case cabinet [R-22GV-F] 1 AY
2- 6 GCABUA860WRPZ Outer case cabinet [R-22GT-F] 1 BD
2- 7 FFPF-A016WRK0 Vibration-proof sheet 1 AU
2- 8 TMAPCA772WRRZ Schematic diagram 1 AE
CONTROL PANEL PARTS
3- 1 DPWBFC507WRUZ Control unit [R-22GV-F] 1 BN
3- 1 DPWBFC452WRKZ Control unit [R-22GT-F] 1 BN
3- 1A QCNCMA308DRE0 4-pin connector (CN-A) 1 AC
3- 1B QCNCMA312DRE0 3-pin connector (CN-B) 1 AB
3- 1C QCNCMA039DRE0 3-pin connector (CN-H) 1 AB
3- 1D QCNCWA030DRE0 12-pin connector (CN-G) 1 AE
3- 1E QLUGPA012DRE0 Tab terminal (TB1,TB2) 2 AB
C1 VCEAB51EW228M Capacitor 2200 uF 25V 1 AE
C2 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C3 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C4 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C5 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C6 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C7 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C8-9 VCKYD11HF104Z Capacitor 0.1 uF 50V 2 AB
C20 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AM
C21 VCEAB31EW106M Capacitor 10 uF 25V 1 AA
C30 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C31 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C60 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C61 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C62 VRD-Q12EF104J Resistor 100k ohm 1/4W 1 AA
C63 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C64 VRD-Q12EF562J Resistor 5.6k ohm 1/4W 1 AA
C70 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C100 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C101 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
CF1 RCRS-A010DRE0 Ceramic resonator CST4.00MGW 1 AD
D1-4 VHD10EDB10+-1T Diode (10EDB10) 4 AB
D20-22 VHD1SS270A/-1 Diode (1SS270A) 3 AA
D23 VHD10EDB10+-1T Diode (10EDB10) 1 AB
D70 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D100-101 VHD1SS270A/-1 Diode (1SS270A) 2 AA
IC1 RH-IZA633DRE0 LSI 1 AW
IC2 RH-IZA980DRE0 IC (AT24C02-10PC2.5) 1 AN
