41
R-22GV
R-22GT
R-23GT
R-24GT
REF. NO. PART NO. DESCRIPTION Q'TY CODE
C60 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C61 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C62 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C63-64 VCKYD11CY103N Capacitor 0.01 uF 16V 2 AA
C70 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C100 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C101 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
CF1 RCRS-A010DRE0 Ceramic resonator CST4.00MGW 1 AD
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D20-22 VHD1SS270A/-1 Diode (1SS270A) 3 AA
D23 VHD11ES1///-1 Diode (11ES1) 1 AB
D70 VHD1SS270A/-1 Diode (1SS270A) 1 AA
D100-101 VHD1SS270A/-1 Diode (1SS270A) 2 AA
IC1 RH-IZA633DRE0 LSI 1 AW
IC2 RH-IZA521DRE0 IC (X24C02P) 1 AL
IC3 RIC—A025BDE0 IC (KID65004AP) 1 AE
LED1 VHPSL3966T/1B Light emitting diode 1 AS
Q1 RIC—A022BDE0 IC (KIA7805P1) 1 AE
Q2 VSDTA123ES/-3 Transistor (DTA123ES) 1 AA
Q3 RH-TZA036CBE0 Transistor (KRC101M) 1 AA
Q20 VSDTB143ES/-3 Transistor (DTB143ES) 1 AC
Q21 RH-TZA036CBE0 Transistor (KRC101M) 1 AA
Q22-23 VSDTD143ES/-3 Transistor (DTD143ES) 2 AC
Q60 RH-TZA037CBE0 Transistor (KRA101M) 1 AA
R1-2 VRD-Q12EF471J Resistor 470 ohm 1/4W [R-23GT] 2 AA
R1-2 VRD-Q12EF471J Resistor 470 ohm 1/4W [R-24GT] 2 AA
R3-5 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 3 AA
R30 VRD-Q12EF101J Resistor 100 ohm 1/4W 1 AA
R31 VRD-Q12EF153J Resistor 15k ohm 1/4W 1 AA
R32 VRD-Q12EF272J Resistor 2.7k ohm 1/4W 1 AA
R33 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 1 AA
R40 VRD-Q12EF272J Resistor 2.7k ohm 1/4W 1 AA
R50-58 VRD-Q12EF101J Resistor 100 ohm 1/4W 9 AA
R60 VRD-Q12EF112J Resistor 1.1k ohm 1/4W 1 AA
R61 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 1 AA
R62 VRD-Q12EF203J Resistor 20k ohm 1/4W 1 AA
R63 VRD-Q12EF152J Resistor 1.5k ohm 1/4W 1 AA
R64 VRD-Q12EF472J Resistor 4.7 ohm 1/4W 1 AA
R65 VRD-Q12EF682J Resistor 6.8 ohm 1/4W 1 AA
R66 VRD-Q12EF472J Resistor 4.7 ohm 1/4W 1 AA
R70-71 VRD-Q12EF472J Resistor 4.7 ohm 1/4W 2 AA
R80-88 VRD-Q12EF472J Resistor 4.7 ohm 1/4W 9 AA
R100 VRN-R12EK621F Resistor 620 ohm (F) 1/4W [R-22GV, R-22GT] 1 AA
R100 VRN-R12EK821F Resistor 820 ohm (F) 1/4W [R-23GT, R-24GT] 1 AA
R101 VRD-Q12EF104J Resistor 100k ohm 1/4W 1 AA
R102 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 1 AA
(J5) VRD-Q12EF103J Resistor 10k ohm 1/4W [R-23GT] 1 AA
(J5) VRD-Q12EF203J Resistor 20k ohm 1/4W [R-24GT] 1 AA
(J6) VRD-Q12EF203J Resistor 20k ohm 1/4W [R-23GT] 1 AA
(J6) VRD-Q12EF103J Resistor 10k ohm 1/4W [R-24GT] 1 AA
RY1 RRLY-A071DRE0 Relay (OJE-SS-112LM) 1 AG
RY2-3 RRLY-A094DRE0 Relay (OMIF-S-112LM) 2 AN
SP1 RALM-A003DRE0 Buzzer (PS3025P02) 1 AG
T1 RTRNPA094DRE0 Touch control transformer [R-22GV, R-22GT] 1 AQ
T1 RTRNPA095DRE0 Touch control transformer [R-23GT, R-24GT] 1 AU
CT1 RTRN-026CHRE0 Current transformer 1 AH
VRS1 RH-VZA034DRE0 Varistor (10G471K) 1 AD
VRS2 RH-VZA034DRE0 Varistor (10G471K) [R-23GT, R-24GT] 1 AD
ZD1 VHEHZ12B1//-1 Zener diode (HZ12B1) [R-23GT, R-24GT] 1 AB
ZD2 VHEHZ4A2///-1 Zener diode (HZ4A2) 1 AA
3- 2 FPNLCB147WRK0 Control panel frame with key unit
[R-22GT, R-23GT, R-24GT] 1
AZ
3- 2 FPNLCB148WRK0 Control panel frame with key unit [R-22GV] 1 AZ
3- 2-1 FUNTKA670WRE0 Key unit [R-22GT, R-23GT, R-24GT] 1 AT
3- 2-1 FUNTKA671WRE0 Key unit [R-22GV] 1 AT
3- 2-2 HDECAA193WRP0 Decoration metal fittings 1 AP
3- 2-3 PCUSUA303WRE0 Cushion 1 AA
3- 3 LANGTA243WRW0 Control panel mounting angle 1 AF
3- 4 XEPSD30P10XS0 Screw; control unit mounting 5 AA
3- 5 XEPSD40P12000 Screw; control panel mounting angle mounting 1 AA
3- 6 XHTSD40P08TV0 Screw; decoration panel mounting for earth 1 AA
OVEN PARTS
