Sharp R-22GV - Parts List

40
R-22GV
R-22GT
R-23GT
R-24GT
◊Refer to "IMPORTANT" described at end of parts list.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
PARTS LIST
◊
◊
◊
◊
ELECTRIC PARTS
1- 1 FH-HZA044WRE0 Magnetron thermistor 1 AN
1- 2 QSOCLA010WRE0 Oven lamp socket [R-22GV, R-22GT] 1 AF
1- 2 QSOCLA010WRE0 Oven lamp socket [R-23GT, R-24GT] 2 AF
1- 3 FH-HZA047WRE0 Intake thermistor 1 AL
1- 4 RMOTEA315WRE0 Blower motor [R-22GV, R-22GT] 1 BE
1- 4 RMOTEA316WRE0 Blower motor [R-23GT, R-24GT] 1 BH
1- 5 QFSHDA018WRE0 Fuse holder 1 AL
1- 6 QACCDA018WRE0 Power supply cord [R-22GV, R-22GT] 1 AY
1- 6 QACCDA015WRE0 Power supply cord [R-23GT, R-24GT] 1 AW
1- 7 DH-HZA009WRK0 Oven thermistor 1 AP
1- 8 FW-QZA100WRK0 High voltage rectifier assembly 1 AX
1- 9 FFS-BA012WRK0 Monitor switch and fuse assembly [R-22GT,R-22GV] 1 AH
1- 9 FFS-BA015WRK0 Monitor switch and fuse assembly [R-23GT, R-24GT] 1 AK
1-10 QSW-MA020WRE0 Voltage select switch [R-23GT,R-24GT] 4 AF
1-11 QSW-MA051WRE0 Secondary inter lok switch and Door sensing switch 3 AG
1-12 RC-QZA189WRE0 High voltage capacitor [R-22GV, R-22GT] 2 AX
1-12 RC-QZA191WRE0 High voltage capacitor [R-23GT, R-24GT] 2 AY
1-13 RLMPTA027WRE0 Oven lamp [R-22GV, R-22GT] 1 AG
1-13 RLMPTA030WRE0 Oven lamp [R-24GT, R-23GT] 2 AF
1-14 RMOTDA209WRE0 Stirrer motor 2 AR
1-15 RTHM-A037WRE0 Magnetron thermal cut-out 145˚C 1 AG
1-16 RTHM-A057WRE0 Magnetron thermal cut-out 145˚C 1 AG
1-17 RTHM-A015WRE0 Blower motor thermal cut-out 115˚C 1 AG
1-18 RTHM-A083WRE0 Oven thermal cut-out 115˚C 1 AH
1-19 RTRN-A453WRE0 Power transformer [R-22GV, R-22GT] 2 BK
1-19 RTRN-A454WRE0 Power transformer [R-23GT] 2 BM
1-19 RTRN-A455WRE0 Power transformer [R-24GT] 2 BM
1-20 RV-MZA230WRE0 Magnetron [R-22GV, R-22GT] 2 BF
1-20 RV-MZA189WRE0 Magnetron [R-23GT] 2 BM
1-20 RV-MZA239WRE0 Magnetron [R-24GT] 2 BL
CABINET PARTS
2- 1 FDAI-A183WRW0 Base plate assembly 1 BC
2- 2 PSHEGA006WRE0 Rubber sheet A 2 AF
2- 3 PSHEGA007WRE0 Rubber sheet B 2 AE
2- 4 GCOVAA240WRW0 Rear cabinet [R-22GV, R-22GT] 1 AX
2- 4 GCOVAA239WRW0 Rear cabinet [R-23GT, R-24GT] 1 AW
2- 5 FFTASA072WRY0 Oven lamp access cover assembly [R-22GV] 1 AM
2- 5 FFTASA069WRY0 Oven lamp access cover assembly [R-22GT, R-23GT, R-24GT]1 AN
2-5-1 PCUSU0407WRP0 Cushion 1 AA
2- 6 GCABUA531WRP0 Outer case cabinet [R-22GV] 1 AY
2- 6 GCABUA523WRP0 Outer case cabinet [R-22GT, R-23GT, R-24GT] 1 BA
2- 7 PZETEA071WRP0 Cabinet insulation sheet 1 AF
2- 8 TMAPCA714WRR0 Schematic diagram [R-22GV, R-22GT] 1 AF
2- 8 TMAPCA715WRR0 Schematic diagram [R-23GT, R-24GT] 1 AG
CONTROL PANEL PARTS
3- 1 DPWBFB358WRU0 Control unit [R-22GT] 1 BL
3- 1 DPWBFB360WRU0 Control unit [R-23GT] 1 BL
3- 1 DPWBFB392WRU0 Control unit [R-24GT] 1 BL
3- 1 DPWBFB394WRU0 Control unit [R-22GV] 1 BL
3- 1A QCNCMA308DRE0 4-pin connector (A) 1 AC
3- 1B QCNCMA312DRE0 3-pin connector (B) 1 AB
3- 1C QCNCMA039DRE0 3-pin connector (H) 1 AB
3- 1D QCNCWA030DRE0 12-pin connector (G) 1 AF
3- 1E QCNCMA145DRE0 3-pin connector (D) 1 AB
3- 1F QLUGPA012DRE0 Tab terminal (TAB1,TAB2) 2 AB
C1 VCEAB31EW228M Capacitor 2200 uF 25V 1 AE
C2 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C3 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C4 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C5 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C6 VCKYD11HF104Z Capacitor 0.1 uF 50V 1 AB
C7 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
C8-9 VCKYD11HF104Z Capacitor 0.1 uF 50V 2 AB
C10 VCKYD11CY103N Capacitor 0.01 uF 16V [R-23GT] 1 AA
C10 VCKYD11CY103N Capacitor 0.01 uF 16V [R-24GT] 1 AA
C20 VCEAB31HW104M Capacitor 0.1 uF 50V 1 AB
C21 VCEAB31EW106M Capacitor 10 uF 25V 1 AA
C30 VCEAB31AW476M Capacitor 47 uF 10V 1 AA
C31 VCKYD11CY103N Capacitor 0.01 uF 16V 1 AA
