Sharp R-25JT User Manual

R-25JT-F
42
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
*
4-27 PDUC-A729WRF0 Air duct 1 AL
4-28 PDUC-A564WRW0 Mg exhaust duct 1 AP
4-29 PCUSUA414WRP0 Cushion 1 AD
4-30 LANGKA679WRPZ Fixing angle S 1 AD
4-31 HDECQA147WRM0 Corner cap right 1 AE
4-32 LANGFA195WRW0 Chassis support 1 AG
4-33 LBSHCA014WRE0 Cord bushing 1 AF
4-34 LANGQA593WRPZ Blower motor angle 1 AH
4-35 FFIL-A003WRK0 Air intake filter assembly 1 AV
4-36 HDECEA001WRP0 Decoration sash 1 AR
4-37 HDECQA146WRM0 Corner cap left 1 AE
4-38 PCUSGA409WRP0 Cushion 2 AE
4-39 PCOVPA422WRFZ Splash cover 1 BK
4-40 LANGQA512WRP0 Thermistor angle 1 AE
4-41 LANGKA475WRP0 Switch mounting angle 1 AD
4-42 LANGKA760WRP0 Switch lever 1 AE
4-43 PCUSUA268WRP0 Cushion 1 AA
4-44 MSPRCA101WRE0 Switch lever spring C 1 AC
4-45 LSUB-A133WRPZ Thermo contactor 1 AD
4-46 LANGTA408WRWZ Lamp glass mounting plate 1 AK
4-47 PSPA-A114WRF0 Switch spacer 1 AC
4-48 LSUB-A134WRPZ Hinge support angle 1 AD
DOOR PARTS
5 CDORFB029WRKZ Door assembly 1 BT
5- 2 GCOVAA242WRY0 Door case 1 BD
5- 3 FHNDMA011WRY0 Door lever assembly 1 AP
5- 4 GCOVHA350WRF0 Choke cover 1 AR
5- 5 JHNDMA039WRM0 Door handle 1 AX
5- 6 LANGKA766WRP0 Outside window fixing plate 2 AF
5- 7 PCUSGA430WRP0 Cushion 2 AM
5- 8 PGLSPA457WRE0 Door glass 1 AV
5- 9 PPACGA142WRP0 Door case packing 2 AF
5-10 PGID-0024WRF0 Handle guide 4 AC
5-11 PGID-0025WRF0 Handle spacer 1 AC
5-12 PSPA-A102WRE0 Door case spacer 2 AE
5-13 XHTS740P08RV0 Screw : 4mm x 8mm 9 AG
5-14 FANGKA200WRY0 Latch fixing angle 1 AQ
5-15 FLEVFA019WRY0 Joint lever 1 AP
5-16 LSTPCA002WRM0 Latch head 2 AM
5-17 MLEVPA220WRF0 Head lever 1 AM
5-18 MSPRCA097WRE0 Latch spring 1 AG
5-19 HBDGCA090WRE0 Door badge 1 AF
5-20 PCUSGA486WRP0 Handle cushion 1 AM
MISCELLANEOUS
6- 1 TINSEB105WRRZ Instruction manual 1 AG
6- 2 TLABHA024WRR0 Menu sticker 1 AH
6- 3 FW-VZB755WRE0 Switch harness 1 AQ
6- 4 FW-VZC077WREZ Main wire harness 1 BD
6- 5 LHLDWQ005YBE0 Purse lock LL 1 AA
6- 6 LBNDKA079WRE0 Wire holder 3 AB
6- 7 FW-VZC039WREZ Supply harness 1 AL
6- 8 TCAUAA130WRR0 Lamp caution 1 AC
6- 9 QW-QZA238WRE0 High voltage wire 2 AF
6-10 TCAUAA288WRRZ Monitor caution label 1 AD
6-11 TCAUA0165WRR0 DHHS caution label 1 AB
6-12 TCAUAA279WRRZ Voltage caution label 1 AF
6-13 LHOLDA004WRE0 Cord holder 1 AA
6-14 TCAUAA181WRR0 Filter caution label 1 AC
6-15 TCAUAA165WRR0 User caution 1 AC
6-16 LHLDWQ004YBE0 Purse lock L 1 AA
SCRE,NUTS AND WASHERS
7- 1 XCBWW30P08000 Screw : 3mm x 8mm 6 AB
7- 2 XBPS730P28KS0 Screw : 3mm x 28mm 2 AB
7- 3 XNES730-24000 Nut : 3mm x 2.4mm 4 AE
7- 4 LX-BZA130WRE0 Special screw 1 AD
7- 5 LX-BZA116WRE0 Special screw 2 AD
7- 6 LX-BZA041WRE0 Special screw 2 AA
7- 7 LX-BZA132WREZ Special screw 4 AB
7- 8 LX-BZA138WREZ Special screw 11 AB
7- 9 LX-BZA139WREZ Special screw 1 AA
