A38518, SMEF R-290H(S), O/M, EN
E-4
OVEN DIAGRAM
8. Control panel (See page E-5)
9. Liquid crystal display
10. Waveguide cover
11. Power supply cord
12. Ventilation openings
13. Turntable
14. Roller stay
15. Rating plate
1. Door open button
2. Oven lamp
3. Door hinges
4. Door safety latches
5. See through door
6. Door seals and sealing surfaces
7. Coupling
12
11 15
2
6
3
45
7
0
4
8
1
9
14
13
A38518 R-290H(S) O/M, EN 01-04 03.1.14, 5:56 PM4
