Pin No. Signal I/O Description
25 P41 OUT Terminal not used.
26 P40 IN Connected to VC.
27 RESET IN
Auto clear terminal.
Signal is input to reset the LSI to the initial state when power is applied. Temporarily set "L"
level the moment power is applied, at this time the LSI is reset. Thereafter set at "H" level.
28-29 P71-P70 OUT Terminal not used.
30 XIN IN
Internal clock oscillation frequency input setting.
The internal clock frequency is set by inserting the ceramic filter oscillation circuit with respect
to XIN terminal.
31 XOUT OUT
Internal clock oscillation frequency control output.
Output to control oscillation input of XOUT.
32 VSS IN
Power source voltage: -5.0V.
VC voltage of power source circuit input.
33 P27 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P43 - P46 terminal while one
of G8 line keys on key matrix is touched.
34 P26 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P43 - P46 terminal while one
of G7 line keys on key matrix is touched.
35 P25 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P43 - P46 terminal while one
of G6 line keys on key matrix is touched.
36 P24 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P43 - P46 terminal while one
of G5 line keys on key matrix is touched.
37 P23 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P43 - P46 terminal while one
of G4 line keys on key matrix is touched.
38 P22 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P43 - P46 terminal while one
of G3 line keys on key matrix is touched.
39 P21 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P43 - P46 terminal while one
of G2 line keys on key matrix is touched.
40 P20 OUT
Key strobe signal.
Signal applied to touch-key section. A pulse signal is input to P43 - P46 terminal while one
of G1 line keys on key matrix is touched.
41-44 P17-P14 OUT Terminal not used.
45-51
SEG27-SEG21 OUT Segment data signal.
Connected to LCD.
The relation between signals are as follows:
LSI signal (Pin No.) LCD (Pin No.) LSI signal (Pin No.) LCD (Pin No.)
SEG 27 (45) ....................... S16 (25) SEG 13 (59) ...................... S20 (12)
SEG 26 (46) ....................... S15 (24) SEG 11 (61) ...................... S21 (11)
SEG 25 (47) ....................... S14 (23) SEG 10 (62) ...................... S22 (10)
SEG 24 (48) ....................... S13 (22) SEG 9 (63) ...................... S23 ( 9)
SEG 23 (49) ....................... S12 (21) SEG 8 (64) ...................... S24 ( 8)
SEG 22 (50) ....................... S11 (20) SEG 7 (65) ...................... S25 ( 7)
SEG 21 (51) ....................... S10 (19) SEG 6 (66) ...................... S26 ( 6)
SEG 19 (53) ......................... S9 (18) SEG 5 (67) ........................ S4 ( 5)
SEG 18 (54) ......................... S8 (17) SEG 3 (69) ........................ S3 ( 4)
SEG 17 (55) ......................... S7 (16) SEG 2 (70) ........................ S2 ( 3)
SEG 16 (56) ......................... S6 (15) SEG 1 (71) ........................ S1 ( 2)
SEG 15 (57) ......................... S5 (14) SEG 0 (72) ........................ S0 ( 1)
SEG 14 (58) ....................... S19 (13)
