38
R-320DK
R-320DQ
R-320DW
HOW TO ORDER REPLACEMENT PARTS
To have your order filled promptly and correctly, please furnish the following information.
1. MODEL NUMBER
2. REF. NO.
3. PART NO.
4. DESCRIPTION
Order Parts from the authorized SHARP parts Distributor for your area.
Defective parts requiring return should be returned as indicated in the Service Policy.
∆
∆
∆
∆
∆
*
REF. NO. PART NO. DESCRIPTION Q'TY CODE
4-15 PCUSGA339WRP0 Cushion 2 AG
4-16 PCUSGA533WRP0 Cushion 1 AD
4-17 PCUSUA512WRP0 Cushion 1 AB
4-18 PCUSGA529WRP0 Cushion 1 AC
4-19 PCUSUA527WRP0 Cushion 1 AE
4-20 PCUSUA157WRP0 Cushion 2 AC
4-21 PCUSUA212WRP0 Cushion 1 AB
4-22 PCUSUA474WRP0 Cushion 2 AC
4-23 PCUSUA376WRP0 Cushion 2 AF
4-24 LANG-A065WRWZ Sensor guide 1 AH
4-25 LANGTA365WRPZ Sensor mounting angle 1 AH
DOOR PARTS
5- 1 FDORFA332WRT0 Door panel 1 BD
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GWAKPA694WRRZ Door frame [R-320DK] 1 AX
5- 3 GWAKPA701WRRZ Door frame [R-320DW] 1 AV
5- 3 GWAKPA710WRRZ Door frame [R-320DQ] 1 AT
5- 4 HPNL-A731WRRZ Door screen [R-320DK] 1 AS
5- 4 HPNL-A734WRR0 Door screen [R-320DW] 1 AS
5- 4 HPNL-A739WRR0 Door screen [R-320DQ] 1 AS
5- 5 LSTPPA193WRFZ Latch head 1 AE
5- 6 MSPRTA187WRE0 Latch spring 1 AC
5- 7 XCPSD40P08000 Screw : 4mm x 8mm 4 AA
5- 8 PCUSUA461WRP0 Cushion 1 AB
5- 9 GCOVHA417WRFZ Choke cover 1 AG
MISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AQ
6- 2 NTNT-A079WRE0 Turntable tray 1 AR
6- 3 FW-VZB771WREZ Main wire harness 1 AU
6- 4 QW-QZA150WRE0 High voltage wire B 1 AF
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA166WRR0 DHHS caution label 1 AC
6- 7 TCAUAA254WRR0 Monitor caution label 1
6- 8 TINSEA832WRRZ Instruction book 1 AP
6- 9 TCAUAA255WRR0 Screw caution 1
SCREWS,NUTS AND WASHERS
7- 1 XHPSD40P08K00 Screw : 4mm x 8mm 9 AA
7- 2 XHPSD30P06000 Screw : 3mm x 6mm 3 AA
7- 3 XHTSD40P08RV0 Screw : 4mm x 8mm 5 AA
7- 4 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7- 5 XOTSD40P12RV0 Screw : 4mm x 12mm 3 AA
7- 6 XOTSD40P12000 Screw : 4mm x 12mm 17 AA
7- 7 XOTSF40P08000 Screw : 4mm x 8mm [R-310DK] 1 AA
7- 7 XOTSE40P08000 Screw : 4mm x 8mm [R-310DW] 1 AA
7- 7 XOTSE40P08000 Screw : 4mm x 8mm [R-308DW] 1 AA
7- 8 LX-CZA070WRE0 Special screw (Torx tamper proof screw) 2 AC
7- 9 LX-CZ0052WRE0 Special screw 2 AA
