Sharp R-342 Service Manual

Ref No. Midea Part No. Part Name&Description Pcs/Set Remarks
A01
252100100016
COVER WAVE GUIDE
1
T=0 35 118*99
A01
252100100016
COVER
WAVE
GUIDE
1
T
=
0
.
35
118*99
B01 261501409902 BASE PLATE 1 E25L SGCC T=0.6
B02 256302000004 LEG 4 A17L PP T30
B03 256502500868 ASS'Y BRKT HINGE *U 1 C23L SPCC T=2.5
C01 261300264702 PANEL CONTROL 1 E25L White
C05 261820902664 DECO. MEMBRANE 1
C07 261306014102 BUTTON DOOR OPEN 1 E25L White
C08 252010100001 SPRING BUTTON 1 17L
C13 251306103544 LEVER DOOR OPEN 1 C23L PBT
C18
261400124780
PCB ASS
'
Y
1
EMXEEXU 01 K
C18
261400124780
PCB
ASS'Y
1
EMXEEXU
-
01
-
K
C26 261400209130 SWITCH CIRCUIT 1
C55 261515901000 SHIELD 1 SGCC T=0.5
D01 251500200108 ASS'Y DOOR FRAME 1 E25L SPCD T=0.6
D02 251300500046 LATCH 1 A28L
D03 252010000000 SPRING LATCH 1 25L
D04 256502400556 ASS'Y BRKT HINGE *T 1 A28L SPCC T=2.0
D05 252200400382 BARRIER SCREEN *I 1 E25L PET
D06 262100402834 BARRIER SCREEN *O 1
D07
261300141102
PANEL DOOR
1
E25L White
D07
261300141102
PANEL
DOOR
1
E25L
White
D08 256300600075 GASKET DOOR 1 E28L Black
E01 251200100068 MAGNETRON 1 2M219J 900W
REPLACEMENT PARTS LIST
NOTE:
When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
F
R-342(W)W
or Model:
A00 251500100473 ASS'Y
CAVITY
1
For R-342 models
ASS'Y C/PANEL
1
C00
ASS'Y DOOR
1
D00
After assembly
R-342 Models)
(for
After assembly
R-342 Models)
(for

Sharp R-342 Specifications

General

Brand	Sharp
Model	R-342
Category	Microwave Oven
Language	English
